ARTECO-EVERYWHERE 3.0
Pag. 5
V 3.0 – 23/06/20 Rev 1.0
Chapter 1 – General
Unpacking the Unit
Inspect the packaging that the Arteco Everywhere comes in to ensure it is not damaged.
In the case it is, do not take the device out of the box and inform the courier.
Take all necessary precautions against the risk of damage to the unit due to electrostatic discharge.
Environmental Conditions
from -10° to +55°C (non-condensing)
from +5° to +50°C (non-condensing)
from 30% to 90% (non-condensing)
Links
The device is provided with spring contacts for rapid insertion to accept section conductors between 0.4 and 0.8
mm in diameter (AWG 26 to AWG20).
To connect the wires to the device, lower the orange latch, insert the wire, then release the latch.
The device has a standard RJ45 connector for connectivity and PoE.
Supply
The device can be powered from a PoE source as it is a PD class 2. Alternatively, it can be supplied from a
SELV source (optional) with a voltage of 12 or 24 VDC.
The max 12V consumption is about 300 mA, 24 V 150 mA. See Chapter 2 - CONNECTIONS for more details.
Installation
The device must be installed on a DIN rail in a closed container with no dust or moisture according to the limits
stated above. (See Environmental Conditions).
IN ORDER TO PERFORM A SAFE AND PROPER INSTALLATION PLEASE READ
THIS MANUAL VERY CAREFULLY
