Artopex e-Motion - Components Diagram

3
1 800 378-0189
sac@artopex.com
Components Diagram
Technical Specifications
1.Power input 110-240VAC
2.Power output 24VDC
3.Load capacity 1400N
4.Speed 30 mm/s
5.Stroke 650 mm
6.Min install dimension 590 mm
7.Operation temperature 0-40 degrees celcius
8.Duty cycle Max.10% (or 2 minutes ON / 18 minutes OFF)
Lifting Column Lifting Column
Keypad/Display
Power Cord
Patch
Cord
Control
Box
