ARTROMOT K4 - Page 9

9
Position
Description
Ordernumber
3.20 Joint plate 2.0031.113
3.22 Covering plate 0.0028.105
3.23 Ring 0.0028.106
3.24 Split rivet 0.0031.136
3.26 Retaining ring DIN471A8x0,8
3.27 Rubber buffer 0.0031.109
3.28 Spacer sleeve 0.0031.104
3.29 Pin 2.0031.188
3.30 Countersunk screw DIN7991M5x20vz
3.31 Screw thread pin DIN916M4x4sw
3.32 Screw thread pin DIN914M4x4sw
3.33 Countersunk screw DIN7991M4x10vz
3.34 Hexagonal nut DIN934M5vz
3.35 Pan head crew DIN912M5x6vz
3.36 Countersunk screw DIN7991M5x25A2
3.37 Countersunk screw DIN7991M5x55vz
3.38 Countersunk screw DIN7991M5x16vz
3.39 Bearing plate right 2.0031.103
3.50 Countersunk screw DIN7991M4x16vz
3.51 Pan head screw DIN912M4x12vz
3.53 Spindle nut 2.0032.141
3.54 Sticker ARTROMOT K4 right 2.0031.241
3.55 Sticker ARTROMOT K4 left 2.0031.240
3.60 Housing K4 complete with stickers SN > 10000 0.0031.232
Femur extension
Femur extension assembly (7.1 –7.8) 2.0031.051
7.1 Leaf Spring 2.0031.143
7.2 Stud bolt 2.0031.142
7.3 Square tube 2.0031.025
7.4 Push-button 2.0031.141
7.5 Dwell bolt GN617-5-A-NI
7.6 Countersunk screw DIN7991M4x8A2
7.7 Hexagonal nut DIN985M4vz
7.8 Nut 0.0031.106
Ankle joint
8.5 Washer 0.0031.111
8.10 Fastening band 0.0031.144
8.11 Rigid pipe 2.0031.117
8.12 Knurled handle 2.0031.031
8.13 Washer DIN440D6,6vz
8.14 Hinge box 2.0031.119
