ARTURIA – PROPHET V - MANUAL
49
• Triangle
• Square
PW : knob setting the pulse width signals for the saw, square, and triangle wave-
forms
KBD : connection buttons activating the keyboard
Notice: by turning on the “LO FREQ” button, the oscillator B will ask less CPU power of your computer. A weaker
oscillation frequency will allow you to use it as an LFO for modulating oscillator A or the filter in the “POLY MOD”
section.
 Here are the representations of the different wave-forms used by the oscillators of the
Prophet 5:
Saw tooth
Square
Triangle
