Asano LED2295 - Input Modes and Software; RGB PC and HDMI;DTV Input Specs; Software Upgrade Procedure

852*480 37.684 75.00 31.50 --> 640*480 60Hz Display
3
800*600
37.879 60.31 40.00 VESA
46.875 75.00 49.50
4 1024*768
48.363 60.00 65.00 VESA(XGA)
56.470 70.00 75.00
60.123 75.029 78.75
5 1280*768 47.78 59.87 79.5 WXGA
6 1360*768 47.72 59.8 84.75 WXGA
7 1366*768 47.56 59.6 84.75 WXGA
8.
8.
8.
8. HDMI
HDMI
HDMI
HDMI Input
Input
Input
Input (PC/DTV)
(PC/DTV)
(PC/DTV)
(PC/DTV)
No Resolution H-freq(kHz) V-freq.(Hz) Pixel clock(MHz) Proposed Remark
PC
PC
PC
PC
1 720*400 31.468 70.08 28.321 HDCP
2 640*480 31.469 59.94 25.17 VESA HDCP
3 800*600 37.879 60.31 40.00 VESA HDCP
4 1024*768
48.363 60.00 65.00 VESA(XGA) HDCP
56.470 70.00 75.00
5 1280*768 47.78 59.87 79.5 WXGA HDCP
6 1360*768 47.72 59.8 84.75 WXGA HDCP
7 1366*768 47.56 59.6 84.75 WXGA HDCP
8 1280*1024 63.595 60.0 108.875 SXGA
9 1920*1080 66.647 59.988 138.625 WUXGA
DTV
DTV
DTV
DTV
10 720*480 31.47 59.94 27.00 SDTV 480P(4:3)
11 720*480 31.50 60 27.027 SDTV 480P(4:3)
12 720*480 31.47 59.94 27.000 SDTV 480P(16:9)
13 720*480 31.50 60.00 27.027 SDTV 480P(16:9)
14 720*576 31.25 50.00 27.000 SDTV 576P
15 1280*720 37.50 50.00 74.176 HDTV 720P HDCP
16 1280*720 44.96 59.94 74.176 HDTV 720P HDCP
17 1280*720 45.00 60.00 74.250 HDTV 720P
18 1920*1080 33.72 59.94 74.176 HDTV 1080I HDCP
19 1920*1080 33.75 60.00 74.250 HDTV 1080I HDCP
20 1920*1080 28.125 50.00 74.250 HDTV 1080I 50Hz HDCP
21 1920*1080 27.000 24.00 74.250 HDTV 1080P 24Hz HDCP
22 1920*1080 56.250 50 148.500 HDTV 1080P 50Hz HDCP
23 1920*1080 67.433 59.94 148.352 HDTV 1080P HDCP
24 1920*1080 67.500 60 148.500 HDTV 1080P HDCP
Software
Software
Software
Software upgrade
upgrade
upgrade
upgrade
1.
1.
1.
1. Application
Application
Application
Application Range
Range
Range
Range
This specification sheet is applied to all of the LCD TV with AS-MST6M182VG-LE2 chassis.
2.
2.
2.
2. Designation
Designation
Designation
Designation
1) The adjustment is according to the order which is designated and which must be followed, according to the plan which can be
changed only on agreeing.
2) Power Adjustment: Free V oltage
