(parameters Pb, Ti and Td are visible).
Note: When the Autotuning and the soft start, or the delay at
the start up, have been programmed, the instrument
performs first the soft start (with the parameters it has
in memory) and then performs the Autotuning.
[7] Pb - Proportional band
Available: When o1F = PID and tun = ub.
Range: 1 ÷ 999 engineering units.
[8] ti - Integral time
Available: When o1F = PID and tun = ub.
Range: OFF (excluded)/1 ÷ 500 seconds.
[9] td - Derivative time
Available: When o1F = PID and tun = ub.
Range: OFF (excluded)/1 ÷ 200 seconds.
[10] SEn - Input type
Model Selection Sensor Measuring range
F
J .C TC J -40 ÷ 999°C
Ca.C TC K -40 ÷ 999°C
J .F TC J -40 ÷ 999°F
Ca.F TC K -40 ÷ 999°F
A
Pt.C PT 100 -50.0 ÷ 850°C (autoranging)
Pt.F PT 100 -58.0 ÷ 999°F (autoranging)
T
nC.C NTC -50.0 ÷ 109°C (autoranging)
PC.C PTC -50.0 ÷ 150°C (autoranging)
nC.F NTC -58.0 ÷ 228°F (autoranging)
PC.F PTC -58.0 ÷ 302°F (autoranging)
P1.C Pt 1000 -50.0 ÷ 850°C (autoranging)
P1.F Pt 1000 -58.0 ÷ 999°F (autoranging)
[11] dP - Decimal point
Range:
YES = Autoranging display;
nO = display without decimal point.
[12] CA - Offset on the displayed value
Range: -300 ÷ 300 engineering units.
[13] Ft - Filter on the displayed value
Range: 0 (excluded)/1 ÷ 20 seconds.
[14] o1F - Out1 function
Range:
H.rE = PID control with heating action (reverse);
C.rE = PID control with cooling action (direct);
on.H = ON/OFF control with heating action (reverse);
on.C = ON/OFF control with cooling action (direct).
[15] tr1 - Out1 cycle time
Range: 1 ÷ 250 seconds.
[16] o2F - Out2 function
Range:
- When o1F is equal to H.rE or C.rE:
no = Not used;
HAL = Absolute high alarm;
LAL = Absolute low alarm;
b.AL = Band alarm (simmetric to the set point);
dHA = Deviation high alarm;
dLA = Deviation low alarm.
- When o1F = on.H or on.C:
no = Not used;
HAL = Absolute high alarm;
LAL = Absolute low alarm;
b.AL = Band alarm (simmetric to the set point);
dHA = Deviation high alarm ;
dLA = Deviation low alarm;
SP.C = SP2 - ON /OFF control with cooling action ;
SP.H = SP2 - ON /OFF control with heating action ;
nr = ON/OFF Neutral Zone [o2F will make the opposite ac-
tion to the one programmed on o1F, while the hysteresis
(parameter d1) becomes the neutral zone].
Note: The Neutral Zone functioning is used to control the plants
with an element that causes a positive increase (ex.
Heating, Humidifying etc.) and an element that causes a
negative increase (ex. Cooling, Dehumidifying etc.).
The control works on the programmed outputs depending
on the measure, on the active Set point “SP”, and on the
programmed hysteresis “d1”.
The controller works in the following way: it switches OFF the
outputs when the process value reaches the Set Point and
activates the heating output when the process value is lower
than [SP - d1], or it switches on the cooling output when the
process value is higher than [SP + d1].
Accordingly, the element that causes the positive increase
must be connected to the output programmed as heating,
while the element of negative increase must be connected to
the output programmed as cooling.
O2F = nr
(heating)
O1F = on.H
(heating)
SP
PV
OFF OFF
time
D1
D1
OFF OFF0N
0N
0N
Table of the possible combinations
O1F O2F Displayed parameters
H.rE H.AL, L.AL, b.AL, dHA, dLA SP1, AL
C.rE H.AL, L.AL, b.AL, dHA, dLA SP1, AL
on.H
H.AL, L.AL, b.AL, dHA, dLA SP1, AL
SP.C, SP.H SP1, SP2
Nr SP1 only
on.C
H.AL, L.AL, b.AL, dHA, dLA SP1, AL
SP.C, SP.H SP1, SP2
Nr SP1 only
[17] d1 - Out1 hysteresis or neutral zone
Available: When Out1 is equal to hn.H or on.C.
Range: 0.1 ÷ 999 engineering units.
[18] d2 - Out2 hysteresis
Available: When o2F is different from nr.
Range: 0.1 ÷ 999 engineering units.
[19] AL.F - Alarm function
Available: When o2F is programmed as alarm output.
Range:
AL = Automatic reset Alarm;
AL.n = Latched Alarm;
AL.A = Aknowledgeable Alarm.
AL = Automatic reset Alarm
Time
Measure
Meas
Alx
Alarm hysteresis
Status
ON
OFF
Time
Automatic reset
Automatic
AL.n = Latched Alarm
Time
Measure
Meas
Alx
Alarm hysteresis
Status
ON
OFF
Time
Manual
reset
Manual
reset
Latched
AL.a = Acknowledged Alarm
Time
Measure
Ambient
temp.
Alx
Alarm hysteresis
Status
ON
OFF
Time
Automatic
reset
ACK
Acknowledgeable
[20] AL.t - Inhibition time of the alarm at start up
or after a Set Point change
Range: 0 = OFF (any hidding)/0.01 ÷ 9.59 hh.mm.
Note: When the measure reaches the alarm threshold, the
instrument disables the hidding of the alarm.
[21] Pct - Compressor protection time
The protection prevents the output cycling and therefore re-
duces relay wear by waiting for the time setting to elapse be-
fore allowing a subsequent switching of the output. In other
words, it defines the minimum time that will pass between the
switch off of a cooling output and its following reactivation.
Available:
When at least one output is programmed as
cooling output.
Range: 0 (OFF)/0.01 ÷ 9.59 hh.mm.
Note: This parameter has effect to ALL the cooling outputs.
[22] SSt - Soft start time
Range: 0 (OFF)/0.01 ÷ 9.59 hh.mm.
Note: When the control type is ON/OFF, the time of the soft
start becomes an output time delay, the power is forced
to 0 and the parameter SSP is hidden.
[23] SSP - Power during Soft Start
Available: When Sst is different from 0.
Range: 0 ÷ 100%.
Note: If programmed = 0, also the alarms and/or the second
control output remains = 0 and the instrument displays
od for the programmed time.
[24] ub.F -
U
key function
Range:
no = No function;
Tun = It activates the manual tuning;
Sb = Stand-by mode;
Sb.o = Stand-By mode with display off.
[25] PP - Parameters protection Password
Range: 1 ÷ 999.
[26] Lo - Time for the Key lock automatic enable
This parameter allows to set the time that the instrument will
wait before to automatically enable the key lock. The time
count will re-start after a key pressure.
Range: 0 (lock disabled)/1 ÷ 30 minutes.
6. ERROR MESSAGES
6.1 Out of range signals
The display shows the OVER-RANGE and UNDERRANGE
conditions with the following indications:
Over range
Under range
The sensor break will be signaled as follows:
Sensor break
Note: When an over-range or an under-range is detected, the
alarms operate as in presence of the maximum or the
minimum measurable value respectively.
To check the out of span Error condition, proceed as follows:
1. Check the input signal source and the connecting line;
2. Make sure that the input signal is in accordance with the
instrument configuration. Otherwise, modify the input
configuration (see section 4).
3. If no error is detected, send the instrument to your sup-
plier to be checked.
6.2 List of possible errors
AtE - Auto-tune not finished within 12 hours.
EPr - Possible problem of the instrument memory.
The messages disappear automatically.
When the error continues, send the instrument to your supplier.
7. GENERAL NOTES
7.1 Proper use
Every possible use not described in this manual must be
considered as a improper use.
This instrument is in compliance with EN 61010-1 “Safety re-
quirements for electrical equipment for measurement, control
and laboratory use”; for this reason it must not be used as a
safety equipment.
Ascon Tecnologic S.r.l. and its legal representatives do not
assume any responsibility for any damage to people, things
or animals deriving from violation, wrong or improper use or
in any case not in compliance with the instrument’s features.
m Whenever a failure or a malfunction of the control device
may cause dangerous situations for persons, thing or ani-
mals, please remember that the plant has to be equipped
with additional safety devices.
7.2 Warranty and Repairs
We warrant that the products will be free from defects in mate-
rial and workmanship for 18 months from the date of delivery.
Products and components that are subject to wear due to
conditions of use, service life, and misuse are not covered
by this warranty.
The warranty is limited to repairs or to the
replacement of the instrument.
The tampering of the instrument or an improper use of the
product will bring about the immediate withdrawal of the
warranty’s effects.
In the event of a faulty instrument, either within the period
of warranty or further to its expiry, please contact our sales
department to obtain authorisation for sending the instrument
to our company.
The faulty product must be shipped to Ascon Tecnologic with
a detailed description of the faults found, without any fees or
charge for Ascon Tecnologic, except in the event of alternative
agreements.
Before supplying tension to the instrument, make sure that it
is perfectly dry.
7.3 Disposal
The appliance (or the product) must be
disposed of separately in compliance
with the local standards in force on
waste disposal.
8. PARAMETER TABLES
no. Par. Description Range Default Prot.
1 SPL Minimum Set Point value –99.9 ÷ SPH E.U. -99 Yes
2 SPH Maximum Set Point value SPL ÷ 999 E.U. 999 Yes
3 SP1 Set point SPL ÷ SPH E.U. 0 No
4 SP2 Second Set Point SPL ÷ SPH E.U. 0 Yes
5 AL Alarm threshold –99.9 ÷ 999 E.U. 0 Yes
6 tun Autotuning
ALL Performed at every start up
onE Performed at the first start up
ub Performed when
U
key is pressed
onE Yes
7 Pb Proportional Band 1 ÷ 999 E.U. 50 Yes
8 ti Integral time 0 (OFF)/1 ÷ 500 seconds 100 Yes
9 td Derivative time 0 (OFF)/1 ÷ 200 seconds 25 Yes
10 SEn
Input type
F type
JC TC J (°C)
CA.C TC K (°C)
JF TC J (°F)
CA.F TC K (°F)
J.C
Yes
A type
Pt.C PT 100 (°C)
Pt.F PT 100 (°F)
Pt.C
T type
nC.C NTC (°C)
PC.C PTC (°C)
nC.F NTC (°F)
PC.F PTC (°F)
P1C PT 1000 (°C)
P1F PT 1000 (°F)
nC.C
11 DP Decimal point
YES
Autoranging visualization
no Visualization with no decimal point
no Yes
12 CA
Offset on the displayed value
-300 ÷ 300 E.U. 0 Yes
13 Ft
Filter on the displayed value
0 (OFF)/1 ÷ 20 s 0 Yes
14 O1F Out1 function
H.rE
PID control with heating action
C.rE PID control with cooling action
on.H ON/OFF control with heating action
on.C ON/OFF control with cooling action
HrE Yes
15 tr1 Out1 cycle time 1 ÷ 250 seconds 30 Yes
16
o2F Out2 Function
When: o1F = H.rE or
o1F = C.rE
no Not used
HAL Absolute high alarm
LAL Absolute low alarm
b.AL Band alarm (simmetric to the set point)
dHA Deviation high alarm
dLA Deviation low alarm
No Yes
When: o1F = on.H or
o1F = on.C
no Not used
HAL Absolute high alarm
LAL Absolute low alarm
b.AL Band alarm (simmetric to the set point)
dHA Deviation high alarm
dLA Deviation low alarm
SP.C SP2 ON/OFFcontrol with cooling action
SP.H SP2 ON/OFF control with heating action
nr ON/OFF neutral zone
17 d1 Out1 hysteresis or neutral zone 0.1 ÷ 999 E.U. 1 Yes
18 d2 Out2 hysteresis 0.1 ÷ 999 E.U. 1 Yes
19 ALF Alarm function
AL Automatic reset Alarm
AL.n Latched Alarm
AL.A Ack Alarm
AL Yes
20 ALt
Alarm inhibition time at start up or
after a set point change
0 (OFF)/0.01 ÷ 9.59 hh.mm 0 Yes
21 Pct Compressor protection time 0 (OFF)/0.01 ÷ 9.59 hh.mm 0 Yes
22 Sst Soft start time 0 (OFF)/0.01 ÷ 9.59 hh.mm 0 Yes
23 SSP Power during Soft Start 0 ÷ 100% 0 Yes
24 UbF
To Next Page
Loading...
Need help?
General
