MODEL : A5CKX 20/25A/AR
A5CKX20A A5CKX20AR A5CKX25A A5CKX25AR
1 Assy, Base Pan R50013028745
√√√√
2 Fan Motor HAR067 (CK20A/AR) R03039001735
√√√√
Fan Motor HAR068 (CK25A/AR) R03039001734
√√√√
3 Bush, fan Motor R11014026620
√√√√
4 Plain Washer R07044003768
√√√√
5 Coupling, fan motor Bottom R11054026619
√√√√
6 Turbo Fan Dia. 450mm x 220(d) R03029001613
√√√√
7 Coupling, fan motor Top R11054026610
√√√√
8 Flat Washer R07044003872
√√√√
9 Plain Washer R07044003768
√√√√
10 Spring Washer R07044003769
√√√√
11 Hexagon Bolt M8 x 20mm R07034003822
√√√√
12 Hexagon Bolt M6 x 15mm R07034028746
√√√√
ASSY, COIL 5CK20A/AR R50024082149
√√
ASSY, COIL 5CK25A/AR R50024082148
√√
14 Assy, Drain Pump Support Bracket R50014028765
√√√√
15 Pump, Water PC-04226-OYOB YCK R04139022965
√√√√
16 Bush, Drain Pump R11014026614
√√√√
17 Hexagon Bolt M5 x 27mm R07034028747
√√√√
18 Drain Hose 18.3 x 365mm R10029001615
√√√√
19 Switch Water Lavel 1A - CK Drain Pump R04069022966
√√√√
20 Support, Coil CK 20/25/30/40/50A/AR R01014079035
√√√√
21 Assy, Partition R50014028766
√√√√
22 Side Panel Front R50013028767
√√√√
23 Valve Plate R01014028024
√√√√
24 Drain Connector R12014028769
√√√√
25 Assy, Side Panel back R50013028771
√√√√
26 EPS, AIR Guide R12033028773
√√√√
27 Assy, Drain Pan CK R50123028775
√√√√
28 Fix Bracket Front R50014028779
√√√√
29 Fix Bracket Back R50014028782
√√√√
30 Fan Cover R12010027359
√√√√
ASSY., CONTROL BOX 5CKX 20A R50044086838
√
ASSY., CONTROL BOX 5CKX 25A R50044086839
√
ASSY., CONTROL BOX 5CKX 20AR R50044086840
√
ASSY., CONTROL BOX 5CKX 25AR R50044086841
√
32 Bracket Hanger A R01024037399
√√√√
33 Bracket Hanger B R01024037400
√√√√
34 Bracket hanger C R01024037401
√√√√
35 Assy, Drain Hose R50124025113
√√√√
Parts Not in diagram
CONTROL MODULE, 09A EC VA3 CKX-A 20 R04084086584
√
CONTROL MODULE, 09A AP VA3 CKX-A 20 R04084086609
√
CONTROL MODULE, 09A EC VA3 CKX-A 25 R04084086585
√
CONTROL MODULE, 09A AP VA3 CKX-A 25 R04084086610
√
IONIZER, 220V HB-203D 2 HULIP R04239025327
√√√√
ASSY., BRACKET ION. CKA SERIES R50064082057
√√√√
ASSY. NEGATIVE IONIZER BRACKET R50044084548
√√√√
IONIZER,CARBON FIBER HB-203D 2-50 HUILIP R04239025328
√√√√
PART NUMBER
RELATED MODEL
31
13
No DESCRIPTION
