ascon A5LCX 10 C User Manual

128
MODEL : A5CKX 10/15/20C/CR
A5CKX10C A5CKX10CR A5CKX15C A5CKX15CR A5CKX20C A5CKX20CR
1
ASSY., BASE R50014057906
√√√√√√
2 ASSY., CASING R50014057905
√√√√√√
2 PANEL, SIDE A R01014053369
√√√√√√
2 PANEL, SIDE B R01014053370
√√√√√√
ASSY., COIL 5CKX 10C/CR R50024086667
√√ ----
ASSY., COIL CK15C/CR R50024061114
--√√ - √
ASSY., COIL 5CK20C R50024068865
----√ -
4 COVER,FAN R12014053394
√√√√√√
5 BLOWER WHEEL, TURBO FAN FX330 TU YAMAHA R03029016598
√√√√√√
6 PLATE, WIRE R01014053397
√√√√√√
MOTOR, MCK15C-501 HONG LU R03039016596
√√√√ --
MOTOR, MCK20C-501 HONG LU R03039016597
----√√
8 BUSH, FAN MOTOR R11014049558
√√√√√√
9 BUSH, FAN MOTOR RING R11014049559
√√√√√√
CONTROL MODULE, 09A EC VA3 CKX-C 10 R04084086553
√ -----
CONTROL MODULE, 09A AP VA3 CKX-C 10 R04084086581
- √ ----
CONTROL MODULE, 09A EC VA3 CKX-C 15 R04084086554
--√ ---
CONTROL MODULE, 09A AP VA3 CKX-C 15 R04084086582
---√ --
CONTROL MODULE, 09A EC VA3 CKX-C 20 R04084086580
----√ -
CONTROL MODULE, 09A AP VA3 CKX-C 20 R04084086583
-----√
11 PUMP, WATER PC-04226-OYOB R04139022965
√√√√√√
12 SWITCH WATER LAVEL 1A - CK DRAIN PUMP R04069022966
√√√√√√
13 BUSH,WIRE NR ID22XOD36Xt10 - MODEL CE/SB R11014001876
√√√√√√
14 BUSH,DRAIN PUMP R11014026614
√√√√√√
15 ASSY.,DRAIN PUMP SUPPORT BRACKET R50014054265
√√√√√√
16 ASSY., ENDPLATE SUPPORT R50014057987
√√√√√√
17 CLIP, COIL SENSOR (6mm) R07054021183
√√√√√√
18 TUBE, CU SENSOR HOLDER R02014021112
√√√√√√
19 BRACKET,COIL R01014053398
√√√√√√
20 COVER, TERMINAL R12014053387
√√√√√√
21 COVER, WIRE R12014053396
√√√√√√
22 CONNECTOR,DRAIN CK R12014028769
√√√√√√
23 HOSE,DRAIN CK R10029001615
√√√√√√
24 ASSY, COVER VALVE R50014057903
√√√√√√
25 ASSY., DRAIN PAN CK-C R50064061257
√√√√√√
26 BUSH, RUBBER(EPDM) 25MM U-SHAPE R11014042391
√√√√√√
BRACKET, DRAIN PUMP SUPPORT R01014053375
√√√√√√
COVER, VALVE R01014053399
√√√√√√
COVER, CONTROL BOX R01014053386
√√√√√√
PLATE,PCB MOUNTING R01014053385
√√√√√√
CLAMP, TERMINAL CABLE SL R07054030840
√√√√√√
DRAIN HOSE ASSY CE-D R50124025113
√√√√√√
ASSY.,IONIZER HOLDER CK C SERIES R50014085302
√√√√√√
ASSY, IONIZER CKX-C R50134086592
√√√√√√
IONIZER, 220V HULIP HB-203D3 CKC R04239026587
√√√√√√
ASSY. NEGATIVE IONIZER BRACKET R50044084548
√√√√√√
IONIZER,CARBON FIBER HB-203D 2-50 HUILIP R04239025328
√√√√√√
Parts not in diagram
DESCRIPTION PART NUMBER
RELATED MODEL
3
10
7
No

ascon A5LCX 10 C Specifications

General

Brand	ascon
Model	A5LCX 10 C
Category	Air Conditioner
Language	English
