ascon K V Series User Manual

Ascon Tecnologic - KxxV - Indicators - ENGINEERING MANUAL -V2.0 PAG. 23
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
45 tr.F Independent timer function 0
NonE = Timer not used
i.d.A = Delayed start timer
i.uP.d = Delayed start at power up
i.d.d = Feed-through timer
i.P.L = Asymmetrical oscillator with start in OFF
i.L.P = Asymmetrical oscillator with start in ON
nonE A-62
46 tr.u Timer unit 0
hh.nn = Hours and minutes
nn.SS = Minutes and seconds
SSS.d = Second and tenth of seconds
nn.SS A-63
47 tr.t1 Time 1 2
When tr.u = hh.nn from 00.01 to 99.59
When tr.u = nn.SS from 00.01 to 99.59
When tr.u = SSS.d from 000.1 to 995.9
1.00 A-64
48 tr.t2 Time 2 2
When tr.u = hh.nn from 00.01 to 99.59 + inF
When tr.u = nn.SS from 00.01 to 99.59 + inF
When tr.u = SSS.d from 000.1 to 995.9 + inF
1.00 A-65
49 tr.St Timer status 0
HoLd = timer hold;
run = timer run;
rES = timer reset
rES C-0
]PAn Group - Operator Interface Configuration
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
50 PAS2 Password level 2 0 From 0 (oFF) to 999 (oFF = Level 2 not protected by psw) 20 A-93
51 PAS3 Password level 3 0 From 3 to 999 30 C-0
52 uSrb
button function during run
time
0
nonE = No function
AAc = Alarm reset
ASi = Alarm acknowledge
HoLd = Hold of the measured value
d.Pic = The display will shows the peaks
r.Pic = Peaks reset
0.Pot = Start the 0.Pot routine
r.Pot = 0.Pot routine + Peaks reset
t.Pot = Input calibration with self-learning procedure
Str.t = Timer run/hold/reset
nonE A-94
53 diSP Display management 0
nonE = Standard display
AL1 = Alarm 1 threshold
AL2 = Alarm 2 threshold
AL3 = Alarm 3 threshold
ti.uP = Timer time up
ti.du = Timer time down
nonE A-95
54 Edit Alarm editing enable 0
AE = Alarm thresholds can be modified
AnE = Alarm threshold can NOT be modified
ANe
]Ser Group - Serial Communications Interface Configuration
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
55
Add Address 0 0 (oFF)... 254 1 C-0
56 bAud Baud rate 0
1200 (bit/s);
2400 (bit/s);
9600 (bit/s);
9.2 (kbit/s);
38.4 (kbit/s)
9600 C-0
