Ascon Tecnologic - KxxV - Indicators - ENGINEERING MANUAL -V2.0 PAG. 22
]AL2 Group - Alarm 2 (AL2) configuration
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
21 AL2t Alarm 2 type 0
nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAb = Absolute band alarm
SE.br = Sensor break
HiAb A-54
22 Ab2 Alarm 2 function 0
From 0 to 15
+1 = Not active at power up
+2 = Latched alarm (manual reset)
+4 = Acknowledgeable alarm
0 C-0
23 AL2L
For High and low alarms, it is the low limit of the
AL2 threshold
For band alarm, it is low alarm threshold
dP -1999... AL1H (E.U.) -1999 A-56
24 AL2H
For High and low alarms, it is the high limit of the
AL2 threshold
For band alarm, it is high alarm threshold
dP AL2L... 9999 (E.U.) 9999 A-57
25 AL2 AL2 threshold dP AL2L... AL2H (E.U.) 0 A-58
26 HAL2 AL2 hysteresis dP 1... 9999 (E.U.) 1 A-59
27 AL2d AL2 delay dP 0 (OFF)...9999 (s) oFF C-0
28 AL2o Alarm 2 enable at out of range indication 0
No = Alarm NOT running when out-of-range
YES = Alarm enabled when out-of-range
no C-0
]AL3 Group - Alarm 3 (AL3) configuration
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
29 AL3t Alarm 2 type 0
nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAb = Absolute band alarm
SE.br = Sensor break
nonE C-0
30 Ab3 Alarm 2 function 0
From 0 to 15
+1 = Not active at power up
+2 = Latched alarm (manual reset)
+4 = Acknowledgeable alarm
0 C-0
31 AL3L
For High and low alarms, is the low limit of the AL3 threshold
For band alarm, it is low alarm threshold
dP -1999... AL3H (E.U.) -1999 C-0
32 AL3H
For High and low alarms, is the high limit of the AL3 threshold
For band alarm, it is high alarm threshold
dP AL3L... 9999 (E.U.) 9999 C-0
33 AL3 AL3 threshold dP AL3L... AL3H (E.U.) 0 C-0
34 HAL3 AL3 hysteresis dP 1... 9999 (E.U.) 1 C-0
35 AL3d AL3 delay dP 0 (OFF)...9999 (s) oFF C-0
36 AL3o Alarm 3 enable at out of range indication 0
No = Alarm NOT running when out-of-range
YES = Alarm enabled when out-of-range
no C-0
]AL4 Group - Alarm 4 (AL4) Configuration
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
37 AL4t Alarm 4 type 0
nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAb = Absolute band alarm
SE.br = Sensor break
nonE C-0
38 Ab4 Alarm 4 function 0
From 0 to 15
+1 = Not active at power up
+2 = Latched alarm (manual reset)
+4 = Acknowledgeable alarm
0 C-0
39 AL4L
For High and low alarms, it is the low limit of the AL4 threshold
For band alarm, it is low alarm threshold
dP -1999... AL4H (E.U.) -1999 C-0
40 AL4H
For High and low alarms, it is the high limit of the AL4 threshold
For band alarm, it is high alarm threshold
dP AL4L... 9999 (E.U.) 9999 C-0
41 AL4 AL4 threshold dP AL4L... AL4H (E.U.) 0 C-0
42 HAL4 AL4 hysteresis dP 1... 9999 (E.U.) 1 C-0
43 AL4d AL4 delay dP 0 (OFF)...9999 (s) oFF C-0
44 AL4o Alarm 4 enable at out of range indication 0
No = Alarm NOT running when out-of-range
YES = Alarm enabled when out-of-range
no C-0
]TIN Group - Timer Configuration
