Ascon Tecnologic - KxxV - Indicators - ENGINEERING MANUAL -V2.0 PAG. 21
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
5 o2AL Alarms linked up with the out 2 0
from 0 to 15
+ = Alarm 1
+2 = Alarm 2
+4 = Alarm 3
+8 = Alarm 4
+16 = Sensor break (burn out)
AL1 A-20
6 o2Ac Out 2 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir C-0
7 o3F Out 3 function 0
nonE = Output not used.
AL = Alarm output
t.out = Timer output
t.HoF = Tiemer out - OFF in Hold
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF = Out-of-range, burn out and Power failure indicator
diF.1 = The output repeates the digital input 1 status
diF.2 = The output repeates the digital input 2 status
AL A-22
8 o3AL Alarms linked up with the out 3 0
from 0 to 15
+1 = Alarm 1
+2 = Alarm 2
+4 = Alarm 3
+8 = Alarm 4
+16 = Sensor break (burn out)
AL2 A-23
9 o3Ac Out 3 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir C-0
10 o4F Out 4 function 0
nonE = Output not used.
AL = Alarm output
t.out = Timer output
t.HoF = Tiemer out - OFF in Hold
or.bo = Out-of-range or burn out indicator
P.FAL = Power failure indicator
bo.PF = Out-of-range, burn out and Power failure indicator
diF.1 = The output repeates the digital input 1 status
diF.2 = The output repeates the digital input 2 status
AL A-24
11 o4AL Alarms linked up with the out 4 0
from 0 to 15
+1 = Alarm 1
+2 = Alarm 2
+4 = Alarm 3
+8 = Alarm 4
+16 = Sensor break (burn out)
AL2 A-25
12 o4Ac Out 4 action 0
dir = Direct action
rEU = Reverse action
dir.r = Direct with reversed LED
ReU.r = Reverse with reversed LED
dir C-0
]AL1 Group - Alarm 1 (AL1) Configuration
no. Param. Description
Dec.
Point
Values Default
Vis.
promo
13 AL1t Alarm 1 type 0
nonE = Alarm not used
LoAb = Absolute low alarm
HiAb = Absolute high alarm
LHAb = Absolute band alarm
SE.br = Sensor break
LoAb A-47
14 Ab1 Alarm 1 function 0
From 0 to 15
+1 = Not active at power up
+2 = Latched alarm (manual reset)
+4 = Acknowledgeable alarm
0 C-0
15 AL1L
For High and low alarms, is the low limit of the AL1 threshold
For band alarm, it is low alarm threshold
dP -1999... AL1H (E.U.) -1999 A-48
16 AL1H
For High and low alarms, is the high limit of the AL1 threshold
For band alarm, it is high alarm threshold
dP AL1L... 9999 (E.U.) 9999 A-49
17 AL1 AL1 threshold dP AL1L... AL1H (E.U.) 0 A-50
18 HAL1 AL1 hysteresis dP 1... 9999 (E.U.) 1 A-51
19 AL1d AL1 delay dP 0 (OFF)...9999 (s) oFF C-0
20 AL1o Alarm 1 enable at out of range indication 0
No = Alarm NOT running when out-of-range
YES = Alarm enabled when out-of-range
no C-0
