ASG A680 - Technical Specifications of the A680; Power Input;Output and Performance; Battery Compatibility and Parameters; Operational Limits and Settings

Specification
• DC Input Voltage: 11-18V
• AC Input Voltage: 100-240V
• Display Type: 2x16 LCD
• Display Backlight: Blue
• Case Material: Plastic
• Controls: Four Buttons
• Case Size: 135x110x60mm
• Weight: 390g
• External Port: 1-6S Balance Socket-XH, Temperature Probe Socket, Battery Socket, DC Input.
• Delta Peak Detection for NiMH/NiCd: 3-15mV/cell / Default: 4mV/cell
• Battery Cutoff Temperature: 20
0
C/68
0
F-80
0
C/176
0
F(adjustable)
• Charge voltage NiMH/NiCd: Delta peak detection
o LiPo: 4.18-4.25V/cell Pb Normal: 2.4V/cell
o LiHV: 4.25-4.35V/cell Pb AGM: 2.45V/cell
o LiFe: 3.58-3.7V/cell Pb Cold: 2.45V/cell
o Lilon: 4.08-4.2V/cell DJI: 13.05V
• Balance current: 300mA/cell
• Reading Voltage Range: 0.1-26.1V/cell
• Battery Types/Cells: LiPO/LiHV/LiFe/Lilon: 1-6cells
o NiMH/NiCd: 1-15cells
o Pb: 2-20V DJI: 3cells(LiHV)
• Battery Capacity Range: NiMH/NiCd: 100-50000mAh
o LiPo/LiHV/LiFe/Lilon: 100-50000mAh
o Pb: 100-50000mAh
• Charge current: 0.1A-8.0A
• Safety timer: 1-120 minutes off
• Charge wattage: 80W
• Discharge current: 0.1A-2.0A
• Discharge cut-off voltage: NiMH/NiCd: 0.1-1.1V/cell
o LiPo: 3.0-3.3V/cell LiHV: 3.1-3.4V/cell
o LiFe: 2.6-2.9V/cell Lilon: 2.9-3.2V/cell
o Pb: 1.8-2.0V/cell
• Discharge wattage: 10W
• Balance cells: 2-6 cells
• Memory: 10 different charge/discharge profiles
• Charge method: CC/CV for lithium types and lead (Pb) batteries
Delta-peak sensitivity for NiMH/NiCd
