8.3.9.2 To View – Negative Sequence O/C Settings
NPS Overcurrent
Press the Right arrow key () to move to the next option.
I2>1 Enable
Yes
This window shows the set I2>1 Enable function.
Press the Right arrow key () to move to the next option.
I2>1
100%
This window shows the set I2>1
Press the Right arrow key () to move to the next option.
I2>1 TMS
00.100
This window shows the set I2>1 TMS
Press the Right arrow key () to move to the next option.
I2>1 Curve
IEC S Inverse 1
This window shows the set I2>1 Curve
Press the Right arrow key () to move to the next option.
tI2>1 DT Delay
001.00s
This window shows the set tI2>1 DT Delay
Press the Right arrow key () to move to the next option.
I2>1 tRESET
DT
This window shows the set I2>1 tRESET
Press the Right arrow key () to move to the next option.
tI2>1tRESETDelay
001.00s
This window shows the set tI2>1tRESETDelay
Press the Right arrow key () to move to the next option.
I2>1 2nd Hrm BLK
Disabled
This window shows the set I2>1 2nd Hrm BLK function.
Press the Right arrow key () to move to the next option.
I2>2 Enable
Yes
This window shows the set I2>2 Enable function.
Press the Right arrow key () to move to the next option.
