Z-Axis Drive & Optional F-Axis DB-15M Connector
PIN SIGNAL INFORMATION
5 Z Enc Ch B Z Encoder Channel B
6 GND Ground
7 CLTCH Clutch (+24V)
8 Z Mot + Z Motor +
9 F Enc Ch A F Encoder Channel A
10 Z Lim U Z Upper Limit
11 F Lim U F Upper Limit
12 F Mot + F Motor +
13 Z Enc Ch A Z Encoder Channel A
14 +5V +5V
15 Z Mot - Z Motor -
RS-232 Serial In DB-9F Connector
PIN SIGNAL INFORMATION
2 R In Receive
3 T Out Transmit
5 GND Signal Ground
1,4,6-9 N.C. Not Connected
RS-232 Serial Out DB-9M Connector
PIN SIGNAL INFORMATION
2 T Out Transmit
3 R In Receive
5 GND Signal Ground
1,4,6-9 N.C. Not Connected
Circular Power Connector
PIN SIGNAL INFORMATION
1 +24V +24V Power From Modular Supply.
2 GND C Case Ground
3 GND S Supply Ground
USB Connector
PIN SIGNAL INFORMATION
1 VBUS USB VBUS
2 D+ Data +
3 D- Data -
4 GND Ground
XY Axis Linear Encoder (optional) DB-9M Connector
PIN SIGNAL INFORMATION
1 X Enc Ch A X Encoder Channel A
2 X Enc Ch B X Encoder Channel B
3 GND Signal Ground
4 N.C. Not Connected
5 +5V +5V Power
6 N.C. Not Connected
7 Y Enc Ch A Y Encoder Channel A
8 Y Enc Ch B Y Encoder Channel B
