27
PERFORMANCE INFORMATION
EXAMPLE OF HOW TO LOAD THE MACHINE
TECHNICAL DATA
Height: 820–890 mm
Width: 596 mm
Weight: 48 kg*
51kg with water softener*
Capacity: 14 AS covers
Water pressure: 0.03–1.0 MPa
Water pressure: 0.15–1.0 MPa
1.5–10 kp/cm
2
(Bar)
15-100 N/cm
2
Max. temperature inlet-water: 80° C
Connection: See data plate
Max. power: See data plate
* The weight may vary depending on different
specifications.
TEST DOSES
Pre-wash 5 grammes and Main wash 20 gram-
mes detergent.
STANDARD TESTS
Australia: AS/NZS 2007.1
Dishwashing programmes:
Quick wash 55°C without heated dry
Connection: Cold water
Test method, noise: IEC-704-1
