Model D1976
(DW 955)
Page
Date
2000-06
7
Electrical Supply
The machines are wired for connection to a single-phase, 120V, 15A supply, with a heater power of
1400W, giving a total power requirement of 1600W.
VALUES FOR WIRING DIAGRAMS
Resistance values at 68° F (+/-5°F), 20° C (+/-3°C)
(Values within +/- 10% is normal.)
AP Drain pump 120V, 60 Hz, 25.5 ohm
BB Illumination switch
CP Main pump 120 V, 60 Hz, Main = 10.5 ohm, Aux = 14.5 ohm
KD Combi-dispenser 120 V, 0.31 ohm
EL Heating element 120 V, 1400 W, 10 ohm
F Filter 680 K ohm (1-2, 3-4)
IV Inlet valve 120 V, 9.93 K ohm
FL Fan 120 V, 0.25 K ohm
LB Door switch
LU Door
N Level switch
P Control unit
R Relay 230 V Eberle, 0.59 K ohm
T Thermostat 19–25 K ohm
TB Pushbutton switch
TE Temp. thermistor 18–25 K ohm
WAX Wax motor 1.5–3.0 K ohm
VMG Rinse ag sensor
OB Overflow switch
ELECTRICAL FUNCTIONS
