7
Parts of the dishwasher*
Technical information
Height
Width
Depth
Weight
Capacity*
Water pressure
Connection
Max
Accessories
*In accordance with standard, AS/NZS 2007
**See type plate.
820-860 mm
596 mm
550 mm
48 kg/51 kg
14 place settings
0.03-1.0 MPa (0.3–10 kp/cm
2
)
1-phase, 230 V, 50Hz 10/10A**
1600 W**
Work surface, Side panels, Anti-tilt
1. Knife basket
2. Upper basket
3. Spray arms
4. Cutlery basket
5. Lower basket
6. Rinse aid dispenser
7. Dishwasher detergent compartment
8. Main switch
9. Program panel
10. Filter
11. Type plate
* Details may differ
depending on model and market!
1
3
5
4
6
7
8
9
2
10
11
