Asko DBI663IS.U - Adjusting Height and Sliding into Place

NOTE!
The surface to which the protective film is fitted must be clean and dry.
Adjust the height and slide the dishwasher into place
1. Start by measuring the height from the floor to the bottom edge of the countertop.
2. Measure the height from the floor to the top edge of the dishwasher.
3. Lean the dishwasher forward a little and adjust the rear foot with the screw at the front of the
dishwasher. Turn clockwise to lower or counterclockwise to raise.
4. Adjust the front feet by turning them clockwise to raise and counterclockwise to lower the dish-
washer.
1''
5/8''
5. Verify there is an air gap of at least 1/8'' between the underside of the countertop and the top
edge of the dishwasher.
6. Slide the dishwasher into place.
• Pull the supply and drainage hoses when sliding the dishwasher into place.
• Check that the hoses have no kinks or sharp bends, and check that there is nothing that
can damage the hoses.
37
Installation instructions
