Asko DBI663PHS Design Guide

6 | Asko Customer Care 800.222.7820
ASKO DISHWASHERS
W
OPENING WIDTH
H
OPENING
HEIGHT
D
OPENING
DEPTH
TOP VIEW
SIDE
VIEW FRONT VIEW
NOTE:
3
1
/2" (89) finished returns will be visible and should be finished to match cabinetry.
3
1
/2" (89)
FINISHED
RETURN
FRAMELESS CABINETRY
3
/4"
(19)
TYPICAL
3
1
/2" (89)
FINISHED
RETURN
FILLER
FRAMED CABINETRY
W W
Opening Dimensions
DISHWASHERS IMPORTANT NOTE: All indoor models can accommodate
varying opening widths, however, 24"
(610) and 23
5
/8"
(60 cm) are the two most common. A 23
5
/8" (60 cm) opening
will provide minimum reveals.
OPENING
W H D
Indoor Model 23
5
/8" (600) 34
1
/2" (876) 24" (610)
Outdoor Model 24
7
/8" (632) 35
1
/2" (902) 25
1
/4" (641)
A minimum 3
1
/2" (89) nished return is required on all sides
of the opening. Framed cabinets will require additional
nished ller material behind the face frame for a proper
installation. Refer to the illustration.
Indoor models include top and side trim to accommodate
varying opening dimensions. Top and side trim can be
removed to achieve minimum reveals.
For ADA installations and height restricted openings, all
indoor, non-XXL models can be installed in a 32
1
/4" (819)
opening by removing top trim and lowering side trim.

Asko DBI663PHS Specifications

General

Style	built in
Color	stainless steel
Load Capacity	16 place settings
Number of Cycles	normal wash, eco wash, hygiene wash, time program, plastic wash, rinse and hold, sanitation wash, upper half, lower half, crystal glass, self-cleaning; 11
Drying Type	turbo drying; vented
Noise level	44 dba
Control Type	touchpad
Delay Start	yes
Spray Arms	3
Water Filter	yes
Leak Protection	no
Water Softener	no
Food Disposer	no
Sanitize Settings	no
Half Load	yes
Wi-Fi	no
Smart Home	no
Remote Control	no
Voltage	120 volts
Frequency	60 hz
Current	15 a

Weight and Dimensions

Depth	22 inch
Height	33 3/4 inch
Width	23 7/8 inch
Net Weight	115 lbs.
