ASKO DISHWASHERS
Custom Panel
PANEL READY
IMPORTANT NOTE:
The size of the custom door panel is
directly related to the size of the opening.
The two most common dishwasher opening widths are
24"
(610) and 23
5
/8" (60 cm). For all other widths, the panel
should be
1
/4" (6) less than the opening to achieve minimum
reveals. The minimum panel width is 23
3
/8" (594).
The most common dishwasher opening height is 34
1
/2"
(876)
. The panel dimensions in the chart below are based on
a 34
1
/2" (876) opening, with a 4" (102) toe kick and
3
/8" (10)
top reveal. For all other opening and toe kick heights, the
panel must be adjusted accordingly. The minimum panel
height is 28"
(711). The minimum toe kick height is 4" (102).
Finish all sides of the custom panel. They may be visible
when the door is open.
PANEL DIMENSIONS
W H
23
5
/8" (60 cm) Opening 23
3
/8" (594) 30
1
/8" (765)
24" (610) Opening 23
3
/4" (603) 30
1
/8" (765)
PANEL REQUIREMENTS
Max Weight (including handle) 20 lb (9 kg)
Min Thickness
3
/4" (19)
W
H
Panel dimensions.
ADA CUSTOM PANEL HEIGHT
The American with Disabilities Act limits the countertop
height to 34"
(864). Differing countertop thickness will affect
the overall panel height.
Typical panel dimensions are based on a 32
1
/2" (826)
opening height with a 4"
(102) toe kick and
3
/8" (10) top
reveal. The panel height cannot be less than 28"
(711). Refer
to the chart below for typical panel dimensions.
PANEL DIMENSIONS (ADA)
W H
23
5
/8" (60 cm) Opening 23
3
/8" (594) 28
1
/8" (714)
24" (610) Opening 23
3
/4" (603) 28
1
/8" (714)
PANEL REQUIREMENTS
Max Weight (including handle) 20 lb (9 kg)
Min Thickness
3
/4" (19)
To Next Page
