4.Component description
4.1 Components and measurement values
The specified resistance values apply at room temperature (about 20°C/68°F)
Values within ±10% are considered normal.
COMPONENT DESCRIPTION
Article no. Position Component
8073779 EMC filter 680 kohm
8073780,81 EMC filter 1 Mohm
8079504 Heating element 1600 W
230 V
32 ohm
8079505 Heating element 1200 W
120 V
12 ohm
8078096 Thermistor 60 kohm
8073801,02
Combi disp. 230 V
1.6 kohm
8073803,04
Combi disp. 120 V
0.3 kohm
8078080
8078080
Circ. pump 220/240 V 50
Hz
Primary winding 115 ohm
Circ..pump 220-240 V 50
Hz
Auxiliary winding 260 ohm
8078082
8078082
Circ..pump 120 V 60 Hz Primary winding 31,4 ohm
Circ..pump 120 V 60 Hz Auxiliary winding 76 ohm
8078081
8078081
Circ. pump 220-240 V
60 Hz
Primary winding 78 ohm
Circ. pump 220-240 V
60 Hz
Auxiliary winding 152 ohm
8078087 Drainage pump 200/240 V
50 Hz, 16 l/min
148 ohm
8078088 Drainage pump 200/220 V
60 Hz, 16 l/min
85 ohm
8078089 Drainage pump 120V 60
Hz, 16 l/min
26 ohm
8078084 2-3 Spray arm diverter 230 V
50/60 Hz
8.5 kohm
8078085 2-3 Spray arm diverter 120 V
60 Hz
2.6 kohm
8079502 Inlet valve single 200/240
V, 4 l/min
3.9 kohm
8079503 Inlet valve single 120 V,
4 l/min
0.95 kohm
8079500 Inlet valve fuse 220/240
V, 4 l/min
2 kohm
8079501 Inlet valve fuse 120 V, 4
l/min
0.5 kohm
