4.Component description
4.1 Components and measurement values
The specied resistance values apply at room temperature (about 20°C/68°F)
Values within ±10% are considered normal.
COMPONENT DESCRIPTION
Article no. Position Component Measurement
value
8073779 EMC lter 680 kohm
8073780,81 EMC lter
1 Mohm
8079504
Heater 1600 W 230 V 32 ohm
8079505
Heater 1200 W 120 V 12 ohm
8078096 Thermistor
60 kohm
8073801,02
Combi disp. 230 V 1.6 kohm
8073803,04
Combi disp. 120 V 0.3 kohm
8078080
8078080
Circ. pump 220/240 V 50
Hz
Primary winding
115 ohm
Circ..pump 220-240 V 50
Hz
Auxiliary winding
260 ohm
8078082
8078082
Circ..pump 120 V 60 Hz Primary winding
31,4 ohm
Circ..pump 120 V 60 Hz Auxiliary winding
76 ohm
8078087
Drain pump 200/240 V
50 Hz, 16 l/min
148 ohm
8078089
Drain pump 120V 60 Hz,
16 l/min
26 ohm
8078084 2-3 Spray arm diverter 230 V
50/60 Hz
8.5 kohm
8078085 2-3 Spray arm diverter 120 V
60 Hz
2.6 kohm
8079502 Inlet valve single 200/240
V, 4 l/min
3.9 kohm
8079503 Inlet valve single 120 V,
4 l/min
0.95 kohm
8079500 Inlet valve fuse 220/240
V, 4 l/min
2 kohm
8079501 Inlet valve fuse 120 V, 4
l/min
0.5 kohm
8078090*
8078090 *
Softener salt water
valve 220/240 V
3 kohm
Softener mixer valve
220/240 V
2.33 kohm
