The following conditions apply to the consumption values indicated below:
Temperature of the supply air: 20 °C.
Moisture content of the supply air: 65 %.
Drying temperature: Normal (
), Låg ( ).
Element power: 2500 W
Before tumble drying, cotton textiles are spun at 800 and 1600 rpm (long spin).
All other textiles (non-iron and acryl) are spun at 800 rpm (short spin) before
tumble drying.
Consumption values TD40
PROGRAM MATERIAL DEGREE OF FILLING ENERGY CONSUMPTION PROGRAMTIME
( approx. kWh) (approx. minutes)
800 rpm - 1600 rpm 800 rpm - 1600 rpm
Extra dry Cotton, linen
Max. (5,0 kg) 3,8 - 3,1 120 - 105
Dry Cotton, linen, Max. (5,0 kg) 3,5 - 2,8 110 - 95
Non-iron, poly- Max. (2,5kg) 1,3 --- 55 ---
ester/cotton,
Normal dry Cotton, linen, Max. (5,0 kg) 3,2 - 2,4 95 - 80
Non-iron, poly- Max. (2,5kg) 1,1 --- 50 --
ester/cotton,
Acryl, rayon, Max. (2,5 kg) 1,5 --- 75 ---
acetate,
Irondry Cotton, linen, Max. (5,0 kg) 2,5 - 1,5 95 - 65
