Installation
Built-in installation
ASKO washers can be installed beneath a
cabinet or worktop with a height of 34” to 35”
(863 to 889 mm) or in a closet. There must
be a gap of about ½” (12 mm) all around the
machine, including between the rear edge of
the machine’s top panel and the back wall.
The opening width must be at least 24½” (622
mm). Space must also be available for the ll
and drain hoses. See the illustration below for
measurements and positions. If the washer is
installed in a closet the door must be left open
while the washer is running.
If the drain outlet is higher than 24"(610 mm), the
connections will need to be recessed.
