ASM AllPro Mustang 4700 Plus 110V

Other manuals for ASM AllPro Mustang 4700 Plus 110V

Repair And Parts40 pages

Questions and Answers

V
Victoria BlankenshipAug 10, 2025
Why is my ASM Paint Sprayer motor not operating?
- R
  Randy HoltAug 10, 2025
  The motor of your ASM Paint Sprayer might not be operating due to several reasons. The pressure control knob setting might be too low, so try slowly increasing the pressure. The spray tip or fluid filter could be clogged; relieve the pressure and clear the clog or clean the gun filter. If water or water-based paint has frozen in the sprayer, thaw it in a warm area completely before starting. Also, check the displacement pump connecting rod pin and ensure it is in place and secured with the spring retainer. If the fan won’t turn, the motor may need to be replaced.
G
Gary ThomasAug 25, 2025
What to do if ASM AllPro Mustang 4700 Plus 110V motor runs but pump strokes?
- K
  Karen RamosAug 25, 2025
  If the motor runs and the pump strokes on your ASM Paint Sprayer, make sure the prime valve is closed. Check if the paint supply is empty and refill and reprime the pump if needed. Clean the intake strainer if it's clogged. Ensure the suction tube isn't leaking air by tightening the nut and checking the o-ring on the tube. For further assistance regarding the intake valve ball and piston ball, see Pump Manual 312362. Also, strain paint before using to remove particles that could clog pump. Leaking around the throat packing nut may indicate worn or damaged packings, and for a damaged pump rod, see Pump Manual 312362.
E
Edgar HartNov 15, 2025
What to do if my ASM AllPro Mustang 4700 Plus 110V has low output?
- G
  Gary StevensonNov 15, 2025
  If your ASM Paint Sprayer has low output, it could be due to several factors. A worn spray tip can cause this, so relieve the pressure and replace the tip. Check if the pump continues to stroke when the gun trigger is released. Also, check for a leaking prime valve. Ensure suction tube connections are tight and inspect the o-ring on the suction tube. Reset the building circuit breaker or replace the fuse, and try another electrical outlet. Replace an incorrect extension cord with a correct, grounded one. Also, check leads from motor to circuit board for damaged or loose wire connectors and make sure that worn motor brushes are greater than 1/4 in. (6 mm). Clean motor brushes if they are binding in brush holders. Replace pressure control assembly if there is low stall pressure. Finally, the...
S
samanthakingDec 1, 2025
How to troubleshoot basic electrical issues with my ASM AllPro Mustang 4700 Plus 110V?
- S
  Scott GreerDec 1, 2025
  To troubleshoot basic electrical issues with your ASM Paint Sprayer: * Ensure the ON/OFF switch is in the ON position. * Reset the building circuit breaker or replace the building fuses. Try another outlet. * Replace the extension cord if faulty. * For a blown fuse, replace it after inspecting the motor. * Ensure motor leads are securely fastened and properly connected to the control board, replacing loose terminals and cleaning circuit board terminals as needed. * If the motor thermal switch is faulty, replace the motor. * Install brush cap or replace brushes if leads are damaged. * Replace brushes if their length is less than 1/4 in. (6 mm). * If the motor armature commutator has burn spots, gouges, or extreme roughness, remove the motor and have a motor shop resurfa...
