Aspect NVR-12MPOE-16 User Manual

NETWORK VIDEO RECORDER QUICK START GUIDE
7
ALARM OUT
Alarm relay output port (N/O, N/C, COM).
8
POWER INPUT
Power input for the NVR.
9 LAN (DOWNLINK) (NVR-12M-64)
Network port
used for connecting a network switch
from which network cameras are connected and
powered.
10 AUDIO IN/OUT
RCA connectors for the
connection of microphones and
speakers.
Front Panel
1 – NVR-8MPOE-4, NVR-8MPOE-8
2 - NVR-12MPOE-16, NVR-12MPOE-32
3 - NVR-12M-64
No.
Name
Description
1
IR REMOTE CONTROL RECEIVER
Receives the control signal from included remote control.
2
USB
x2
For connect
ing USB devices such as a mouse
3
STATUS LED
Displays the status of
p
ower,
n
etwork, and
h
ard drive

Aspect NVR-12MPOE-16 Specifications

General

Brand	Aspect
Model	NVR-12MPOE-16
Category	Network Hardware
Language	English
