ASROCK Rack D2163D8UM User Manual

D2163D8UM / D2143D8UM
2 3
English
Internal Connector
COM Header 1
M.2 1 (2230/2242/2260/2280, PCIE(x4)/SATA3 6.0Gb/s)
Auxiliary Panel
Header
1 (include chassis intrusion, location button & LED, front LAN
LED, event log LED)
TPM Header 1
IPMB Header 1
Buzzer 1
Fan Header 1x CPU Fan, 5x system Fan (4 front, 1 rear) (build in CPU active
fansink)
ATX Power 1x (24-pin) + 1x (8-pin)
USB 2.0 Header 1 (1 header for 2 USB2.0 ports)
Type A USB 3.0
Port
1
ME Recovery 1
NMI Button 1
Speaker(4pin) 1
System BIOS
BIOS Ty pe 256Mb AMI UEFI Legal BIOS
BIOS Features - Plug and Play (PnP)
- ACPI 1.1 Compliance Wake Up Events
- SMBIOS 3.1 Support
- ASRock Rack Instant Flash
Hardware Monitor
Temperature - CPU/PCH/DDR/LAN/Storage Temperature Sensing
- MB/Card side/TR1 Temperature Sensing
Fan - CPU/Rear/Front Fan Tachometer
- CPU Quiet Fan (Allow Chassis Fan Speed Auto-Adjust by CPU
Temperature)
- CPU/Rear/Front Fan Multi-Speed Control
Voltage Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore, DRAM,
+1.1V,+1.0V, +BAT, 3VSB, 5VSB
Support OS
OS Microso® Windows®
- Server 2012 R2 (64 bit)
- Server 2016 (64 bit)
Linux®
- RedHat Enterprise Linux Server 6.8 (64 bit) / 7.4 (64 bit)
- CentOS 6.8 (64 bit) / 7. 4 (64 bit)
- SUSE Enterprise Linux Server 11 SP4 (64 bit) / 12 SP3 (64 bit)
- Ubuntu 16.04 (64 bit) / 18.04 (64 bit)
- Fedora Core 26 (64 bit)
- FreeBSD 11 (64 bit)
