1.2 Specications
D2163D8UM / D2143D8UM
MB Physical Status
Form Factor mATX
Dimension 9.6'' x 9.6'' (24.4 cm x24.4 cm)
Processor System
CPU Supports Intel® Xeon® D-2100 Series Processors (Max. 110W)
*D-2161I:90W/ D-2183IT: 100W
Chipset Soc
System Memory
Type - 8 x 288-pin DDR4 DIMM slots
- Supports DDR4 RDIMM and LRDIMM
DIMM Size Per
DIMM
- Quad Channel DDR4 memory technology
- RDIMM / LRDIMM: 128GB, 64GB, 32GB, 16GB, 8GB, 4GB
DIMM
Frequency
RDIMM / LRDIMM: 2666/2400/2133MHz
Voltage 1.2V
Expansion Slot
PCIe 3.0 x 16 1 (PCIE6: x16/x8, switch with PCIE4)
PCIe 3.0 x 8 1 (PCIE4: x0/x8, switch with PCIE6)
Storage
SATA
Controller
Intel® Xeon® D-2100: 12 x SATA3 6.0 Gb/s (8 ports form SFF-
8643, 4 port from SATA 7-pin include 1 SATA DOM)
Ethernet
Interface N/A, no onboard LAN, X722 (SoC integrated)
*Please use a mezzanine type LAN card (type A/B/C)
LAN Controller N/A
Management
BMC Controller ASPEED AST2500 : IPMI (Intelligent Platform Management
Interface) 2.0 with ikvm, vMedia support
IPMI Dedicated
GLAN
1 x Realtek RTL8211E for dedicated management LAN
Features - Watch Dog
- NMI
Graphics
Controller ASPEED AST2500
VRAM 128MB(64MBx16) DDR4
Rear Panel I/O
VGA Port D-sub x 1
Lan Port 1 x RJ45 Dedicated IPMI LAN port
Serial Port 1
UID Button/
UID LED
1
