ASROCK A520M-ITX/ac User Manual

English
7
A520M-ITX/ac
1.3 Motherboard Layout
8
10
11
13
14
15
7
5
9
3
2
1
4
6
DDR4_B1 (64 bit, 288-pin module)
DDR4_A1 (64 bit, 288-pin module)
ATXPWR1
PCIE1
HDL ED RESE T
PLE D PWRBT N
PANE L1
1
1
1
HD_AUDIO1
SATA3 _1_ 3
USB _3_4
1
CPU_FAN1
AMD
A520
SOCKETAM4
CLRCMOS1
RGB_LED1
1
1
ADDR_LED1
1
USB3 _4_5
HDMI1
SATA3 _2_ 4
M2_1
DP1
CHA_FAN2/WP
CHA_FAN1
/WP
1
SPEAKER1
Top:
LINE IN
Cente r:
FRONT
Botto m:
MIC IN
M2_WIFI1
A520M-ITX/ac
RoHS
USB 3.2 Gen1
T: USB3_3
B: USB3_TC_1
RJ-45 LAN
USB 3.2 Gen1
T: USB1
B: USB2
USB 2.0
T: USB1
B: USB2
PS2
Keyboard
/Mous e
ATX 12V1
16
12
BAT1
SATA3 _1_ 3
SATA3 _2_ 4

ASROCK A520M-ITX/ac Specifications

General

Processor socket	Socket AM4
Processor manufacturer	AMD
Compatible processor series	AMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 9 3rd Gen
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2667, 2933, 3200, 3466, 3733, 3800, 3866, 4000, 4133, 4200, 4266, 4333, 4400, 4466 MHz
Component for	PC
Motherboard chipset	-
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Number of HDDs supported	5
Supported storage drive interfaces	M.2, SATA III
Graphics card	Radeon Vega
Number of SATA III connectors	0
USB 3.2 Gen 1 (3.1 Gen 1) connectors	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity	4
BIOS type	UEFI AMI
Cables included	SATA
LAN controller	Realtek RTL8111H
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Harmonized System (HS) code	84733020

Weight and Dimensions

Depth	201 mm
Width	230 mm
