Page #9 background imageLoading...
Page #9 background image
English
3
A520M-ITX/ac
Expansion
Slot
•
1 x PCI Express 3.0 x16 Slot (PCIE1: x16 mode)*
* AMD Ryzen series CPUs (Matisse) supports PCIe riser cards
to extend x8/x8 slots
* Supports NVMe SSD as boot disks
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)
Graphics
•
Integrated AMD Radeon
TM
Vega Series Graphics in Ryzen
Series APU*
* Actual support may vary by CPU
•
DirectX 12, Pixel Shader 5.0
•
Shared memory default 2GB. Max Shared memory supports
up to 16GB.
* e Max shared memory 16GB requires 32GB system memory
installed.
•
Dual graphics output: support HDMI and DisplayPort 1.4
ports by independent display controllers
•
Supports HDMI 2.1 with max. resolution up to 4K x 2K
(4096x2160) @ 60Hz
•
Supports DisplayPort 1.4 Input with max. resolution up to
5K (5120x2880)@120Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI 2.1 Port (Compliant
HDMI monitor is required)
•
Supports HDR (High Dynamic Range) with HDMI 2.1
•
Supports HDCP 2.3 with HDMI 2.1 and DisplayPort 1.4
Ports
•
Supports 4K Ultra HD (UHD) playback with HDMI 2.1 and
DisplayPort 1.4 Ports
•
Supports Microso PlayReady®
Audio
•
7.1 CH HD Audio (Realtek ALC887 Audio Codec)
•
Supports Surge Protection

Other manuals for ASROCK A520M-ITX/ac

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK A520M-ITX/ac and is the answer not in the manual?

ASROCK A520M-ITX/ac Specifications

General IconGeneral
Processor socketSocket AM4
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 3 3rd Gen, AMD Ryzen 5 3rd Gen, AMD Ryzen 7 2nd Gen, AMD Ryzen 9 3rd Gen
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds2133, 2400, 2667, 2933, 3200, 3466, 3733, 3800, 3866, 4000, 4133, 4200, 4266, 4333, 4400, 4466 MHz
Component forPC
Motherboard chipset-
Audio output channels7.1 channels
Motherboard form factormicro ATX
Number of HDDs supported5
Supported storage drive interfacesM.2, SATA III
Graphics cardRadeon Vega
Number of SATA III connectors0
USB 3.2 Gen 1 (3.1 Gen 1) connectors1
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity4
BIOS typeUEFI AMI
Cables includedSATA
LAN controllerRealtek RTL8111H
Wi-Fi standardsWi-Fi 5 (802.11ac)
Bluetooth version4.2
Ethernet interface typeGigabit Ethernet
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Depth201 mm
Width230 mm
