ASROCK AD525PV User Manual

66
66
6
1.21.2
1.21.2
1.2
SpecificationsSpecifications
SpecificationsSpecifications
Specifications
Platform - Mini-ITX Form Factor: 6.7-in x 6.7-in, 17.0 cm x 17.0 cm
- Solid Capacitor for CPU power
CPU - Intel
®
Dual-Core Atom
TM
Processor D525 (AD525PV)
- Intel
®
Atom
TM
Processor D425 (AD425PV)
- Supports Hyper-Threading Technology (see CAUTION 1)
- Supports Untied Overclocking Technology (see CAUTION 2)
- Supports EM64T CPU
Chipset - Southbridge: Intel
®
NM10 Express
Memory - 2 x DDR2 DIMM slots
- Supports DDR2 800/667 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB (see CAUTION 3)
Expansion Slot - 1 x PCI slot
Graphics - Intel
®
Graphics Media Accelerator 3150
- Pixel Shader 2.0, DirectX 9.0
- Max. shared memory 384MB (see CAUTION 4)
- Supports D-Sub with max. resolution up to 2048x1536
@ 60Hz
Audio - 5.1 CH HD Audio (VIA
®
VT1705 Audio Codec)
LAN - PCIE x1 Gigabit LAN 10/100/1000 Mb/s
- Realtek RTL8111DL
- Supports Wake-On-LAN
Rear Panel I/O I/O Panel
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x Parallel Port (ECP/EPP Support)
- 1 x Serial Port: COM1
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
Connector - 2 x SATAII 3.0 Gb/s connectors, support NCQ, AHCI and Hot
Plug functions (see CAUTION 5)
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- CD in header
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
(see CAUTION 6)

ASROCK AD525PV Specifications

General

Brand	ASROCK
Model	AD525PV
Category	Motherboard
Language	English
