HDMI_SPDIF Header HDMI_SPDIF header, providing
(3-pin HDMI_SPDIF1) SPDIF audio output to HDMI VGA
(see p.2 No. 28) card, allows the system to
connect HDMI Digital TV/
projector/LCD devices. Please
connect the HDMI_SPDIF
connector of HDMI VGA card to
this header.
HDMI_SPDIF Cable Please connect the black end (A)
(Optional) of HDMI_SPDIF cable to the
HDMI_SPDIF header on the
motherboard. Then connect the
white end (B or C) of
HDMI_SPDIF cable to the
HDMI_SPDIF connector of HDMI
VGA card.
A. black end B. white end (2-pin) C. white end (3-pin)
USB Bracket This USB bracket can support 2
additional USB 2.0 ports besides
the I/O panel. Please connect
the blue connector on the cable
of this USB bracket to the USB
2.0 header (USB2_3, USB4_5,
USB6_7 or USB8_9) and fasten
the USB bracket to the chassis
with screws.
