AM1H-ITX
11
English
No. Description
1 CPU Fan Connector (CPU_FAN1)
2 Power Fan Connector (PWR_FAN1)
3 Chassis Speaker Header (SPEAKER1)
4 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_A2)
5 ATX Power Connector (ATXPWR1)
6 Chassis Intrusion Header (CI1)
7 SATA Power Connector (SATA_POW1)
8 SATA3 Connector (SATA3_1)
9 SATA3 Connector (SATA3_2)
10 SATA3 Connector (SATA3_A2)
11 SATA3 Connector (SATA3_A1)
12 System Panel Header (PANEL1)
13 Chassis Fan Connector (CHA_FAN1)
14 USB 3.0 Header (USB3_2_3)
15 TPM Header (TPMS1)
16 COM Port Header (COM1)
17 USB 2.0 Header (USB4_5)
18 Clear CMOS Jumper (CLRCMOS1)
19 USB 2.0 Header (USB2_3)
20 Front Panel Audio Header (HD_AUDIO1)
