ASROCK B150M-ITX User Manual

2
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 Chassis Fan Connector (CHA_FAN1)
5 ATX Power Connector (ATXPWR1)
6 USB 2.0 Header (USB_9_10)
7 USB 3.0 Header (USB3_7_8)
8 TPM Header (TPMS1)
9 System Panel Header (PANEL1)
10 Chassis Speaker Header (SPEAKER1)
11 Clear CMOS Jumper (CLRMOS1)
12 SATA3 Connector (SATA3_0)
13 SATA3 Connector (SATA3_1)
14 SATA3 Connector (SATA3_2)
15 SATA3 Connector (SATA3_3)
16 Chassis Intrusion Header (CI1)
17 Front Panel Audio Header (HD_AUDIO1)
18 USB 2.0 Header (USB11)

ASROCK B150M-ITX Specifications

General

Brand	ASROCK
Model	B150M-ITX
Category	Motherboard
Language	English
