No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 ATX Power Connector (ATXPWR1)
7 USB 3.1 Gen1 Header (USB3_5_6)
8 SATA3 Connector (SATA3_0)
9 SATA3 Connector (SATA3_1)
10 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
11 SATA3 Connector (SATA3_2)
12 SATA3 Connector (SATA3_3)
13 SATA3 Connector (SATA3_5)
14 SATA3 Connector (SATA3_4)
15 Clear CMOS Jumper (CLRMOS1)
16 Chassis Intrusion and Speaker Header (SPK_CI1)
17 System Panel Header (PANEL1)
18 USB 2.0 Header (USB3_4)
19 USB 2.0 Header (USB5)
20 TPM Header (TPMS1)
21 COM Port Header (COM1)
22 Front Panel Audio Header (HD_AUDIO1)
23 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
