ASROCK B365M Pro4-F User Manual

English
2
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 ATX Power Connector (ATXPWR1)
7 USB 3.2 Gen1 Header (USB3_5_6)
8 SATA3 Connector (SATA3_2)
9 SATA3 Connector (SATA3_3)
10 SATA3 Connector (SATA3_5)
11 SATA3 Connector (SATA3_4)
12 Chassis Intrusion and Speaker Header (SPK_CI1)
13 System Panel Header (PANEL1)
14 SATA3 Connector (SATA3_0)
15 SATA3 Connector (SATA3_1)
16 USB 2.0 Header (USB5_6)
17 USB 2.0 Header (USB3_4)
18 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
19 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
20 TPM Header (TPMS1)
21 Clear CMOS Jumper (CLRMOS1)
22 COM Port Header (COM1)
23 Front Panel Audio Header (HD_AUDIO1)
24 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)

ASROCK B365M Pro4-F Specifications

General

Processor socket	LGA 1151 (Socket H4)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Certification	FCC, CE, ErP/EuP ready
Component for	PC
Motherboard chipset	Intel B365
Audio output channels	7.1 channels
Motherboard form factor	micro ATX
Windows operating systems supported	Windows 10 x64
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	4
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	2133, 2400, 2666 MHz
BIOS type	UEFI AMI
ACPI version	6.0
BIOS memory size	1024 Mbit
System Management BIOS (SMBIOS) version	2.7
HDCP	No
DirectX version	12.0
Maximum resolution	4096 x 2160 pixels
Parallel processing technology support	CrossFireX, Quad-GPU CrossFireX
Wi-Fi	-
LAN controller	Intel® I219-V
Ethernet interface type	Gigabit Ethernet
PCI Express x1 (Gen 3.x) slots	1
PCI Express x16 (Gen 3.x) slots	2
Number of SATA III connectors	6
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Supported storage drive interfaces	SATA III

Weight and Dimensions

Depth	229 mm
Width	244 mm
