Page #11 background imageLoading...
Page #11 background image
English
4
•
PCB Isolate Shielding
•
Impedance Sensing on Rear Out port
•
Individual PCB Layers for R/L Audio Channel
•
15μ Gold Audio Connector
•
Nahimic Audio
LAN
•
2.5 Gigabit LAN 10/100/1000/2500 Mb/s
•
GigaLAN Intel® I225V
•
Supports Wake-On-LAN
•
Supports Lightning/ESD Protection
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Wireless
LAN
•
Intel® 802.11ax WiFi Module
•
Supports IEEE 802.11a/b/g/n/ax
•
Supports Dual-Band (2.4/5 GHz)
•
Supports WiFi6 802.11ax (2.4Gbps)
•
2 antennas to support 2 (Transmit) x 2 (Receive) diversity
technology
•
Supports Bluetooth 5.1 + High speed class II
•
Supports MU-MIMO
Rear Panel
I/O
•
2 x Antenna Ports
•
1 x HDMI Port
•
1 x DisplayPort 1.4
•
1 x USB 3.2 Gen2 Type-A Port (10 Gb/s) (Supports ESD
Protection)
•
1 x USB 3.2 Gen2 Type-C Port (10 Gb/s) (Supports ESD
Protection)
•
4 x USB 3.2 Gen1 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Line in / Front Speaker / Microphone
Storage
•
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
•
1 x Hyper M.2 Socket (M2_1), supports M Key type 2280 M.2
PCI Express module up to Gen4x4 (64 Gb/s) (with Matisse)
or Gen3x4 (32 Gb/s) (with Renoir)*

Other manuals for ASROCK B550 Phantom Gaming-ITX/ax

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B550 Phantom Gaming-ITX/ax and is the answer not in the manual?

ASROCK B550 Phantom Gaming-ITX/ax Specifications

General IconGeneral
Processor socketSocket AM4
Processor manufacturerAMD
Compatible processor seriesAMD Ryzen 3, AMD Ryzen 5
Memory channelsDual-channel
Memory slots typeDIMM
Unbuffered memoryYes
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds2133, 2400, 2667, 2933, 3200, 3466, 3600, 3733, 3800, 3866, 4000, 4133, 4200, 4266, 4333, 4400, 4466, 4533, 4600, 4666, 4733, 4800, 4866, 4933, 5000 MHz
Supported storage drive typesHDD & SSD
Supported storage drive interfacesM.2, SATA III
Parallel processing technology supportNot supported
USB 2.0 connectors1
Number of SATA III connectors4
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controllerIntel I225-V
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 6 (802.11ax)
Bluetooth version5.2
Top Wi-Fi standardWi-Fi 6 (802.11ax)
Ethernet interface type2.5 Gigabit Ethernet
Component forPC
Motherboard chipsetAMD B550
Audio output channels7.1 channels
Motherboard form factormini ITX
Windows operating systems supportedWindows 10 x64, Windows 11 x64
BIOS typeUEFI AMI
ACPI version5.1
BIOS memory size256 Mbit
System Management BIOS (SMBIOS) version2.3
Cables includedSATA
Weight and Dimensions IconWeight and Dimensions
Width170 mm
