B550 Phantom Gaming-ITX/ax
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 Addressable LED Header (ADDR_LED1)
4 RGB LED Header (RGB_LED1)
5 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
6 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
7 ATX Power Connector (ATXPWR1)
8 SATA3 Connectors (SATA3_1_2)
9 SATA3 Connectors (SATA3_3_4)
10 USB 3.2 Gen1 Header (USB3_5_6)
11 System Panel Header (PANEL1)
12 USB 2.0 Header (USB_1_2)
13 Front Panel Type C USB 3.2 Gen2 Header (USB32_TC_2)
14 Clear CMOS Jumper (CLRCMOS1)
15 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
16 Chassis Speaker Header (SPEAKER1)
17 Front Panel Audio Header (HD_AUDIO1)
