Page #115 background imageLoading...
Page #115 background image
111
B560M-ITX/ac
한 국 어
그래픽
Intel® UHD 그래픽스 빌트 - 비주얼과 VGA 출력은 GPU
프로세서로만 지원할 있습니다 .
11
th
Gen Intel® Core
TM
프로세서는 Intel® X
e
Graphics
Architecture(Gen 12) 지원합니다 . 10
th
Gen Intel® Core
TM
로세서는 Gen 9 Graphics 지원합니다 .
그래픽 , 미디어 & 컴퓨팅 : Microso DirectX 12, OpenGL
4.5, Intel® Built In Visuals, Intel® Quick Sync Video, Hybrid /
Switchable Graphics, OpenCL 2.1
디스플레이 & 콘텐츠 보안 : Rec. 2020(Wide Color Gamut),
Microso PlayReady 3.0, UHD/HDR 블루레이 디스크
이중 그래픽 출력 : 독립적 디스플레이 컨트롤러로 HDMI
DisplayPort 1.4 포트 지원
HDMI 2.0 지원 ( 최대 해상도 4K x 2K (4096x2160) @ 60Hz)
DisplayPort 1.4 지원 ( 최대 해상도 4K x 2K (4096x2304) @
60Hz)
Auto Lip Sync, Deep Color (12bpc), xvYCC HBR (High Bit
Rate Audio)(HDMI 2.0 포트 포함 ) 지원 (HDMI 호환 모니터
필요 )
HDCP 2.3(HDMI 2.0 DisplayPort 1.4 포트 포함 ) 지원
HDMI 2.0 DisplayPort 1.4 포트를 이용한 4K Ultra
HD(UHD) 재생 지원
* 11
th
Gen Intel® Core
TM
프로세서는 HDMI 2.0 지원합니다 . 10
th
Gen Intel® Core
TM
프로세서는 HDMI 1.4 지원합니다 .
오디오
7.1 CH HD 오디오 (Realtek ALC897 오디오 코덱 )
서비 보호 지원
LAN
Gigabit LAN 10/100/1000 Mb/s
Giga PHY Intel® I219V
Wake-On-LAN 지원
번개 /ESD 보호 지원
절전형 이더넷 802.3az 지원
PXE 지원
무선 LAN
Intel® 802.11ac WiFi 모듈
IEEE 802.11a/b/g/n/ac 지원
듀얼 밴드 (2.4/5 GHz) 지원
최대 433Mbps 고속 무선 연결 지원
Bluetooth 4.2 / 3.0 + 고속 클래스 II 지원

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B560M-ITX/ac and is the answer not in the manual?

ASROCK B560M-ITX/ac Specifications

General IconGeneral
Processor socketLGA 1200 (Socket H5)
Processor manufacturerIntel
Compatible processor seriesIntel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors1
Non-ECCYes
Memory channelsDual-channel
Memory slots typeDIMM
Number of memory slots2
Supported memory typesDDR4-SDRAM
Maximum internal memory64 GB
Supported memory clock speeds4400, 4600 MHz
Supported storage drive interfacesM.2, SATA III
Parallel processing technology support-
Number of SATA III connectors4
USB 3.2 Gen 2 (3.1 Gen 2) connectors0
DisplayPort version1.4
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controllerIntel® I219-V
Wi-Fi standards802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version4.2
Ethernet interface typeGigabit Ethernet
Component forPC
Motherboard chipsetIntel B560
Audio output channels7.1 channels
Motherboard form factormini ITX
BIOS typeUEFI AMI
ACPI version6.0
System Management BIOS (SMBIOS) version2.7
Cables includedSATA
Harmonized System (HS) code84733020
Weight and Dimensions IconWeight and Dimensions
Width170 mm
