ASROCK B560M-ITX/ac User Manual

English
7
B560M-IT X/ac
1.2 Specications
Platform
•
Mini-ITX Form Factor
•
Solid Capacitor design
CPU
•
Supports 10
th
Gen Intel® Core
TM
Processors and 11
th
Gen
Intel® Core
TM
Processors (LGA1200)
•
Digi Power design
•
6 Power Phase design
•
Supports Intel® Turbo Boost Max 3.0 Technology
Chipset
•
Intel® B560
Memory
•
Dual Channel DDR4 Memory Technology
•
2 x DDR4 DIMM Slots
•
11
th
Gen Intel® Core
TM
Processors support DDR4 non-ECC,
un-buered memory up to 4600+(OC)*
•
10
th
Gen Intel® Core
TM
Processors support DDR4 non-ECC,
un-buered memory up to 4400+(OC)*
* 11
th
Gen Intel® Core
TM
(i9/i7/i5) support DDR4 up to 3200;
Core
TM
(i3), Pentium® and Celeron® support DDR4 up to 2666.
* 10
th
Gen Intel® Core
TM
(i9/i7) support DDR4 up to 2933; Core
TM
(i5/i3), Pentium® and Celeron® support DDR4 up to 2666.
* Please refer to Memory Support List on ASRock's website for
more information. (http://www.asrock.com/)
•
Supports ECC UDIMM memory modules (operate in non-
ECC mode)
•
Max. capacity of system memory: 64GB
•
Supports Intel® Extreme Memory Prole (XMP) 2.0
Expansion
Slot
11
th
Gen Intel® Core
TM
Processors
•
1 x PCI Express 4.0 x16 Slot*
10
th
Gen Intel® Core
TM
Processors
•
1 x PCI Express 3.0 x16 Slot*
* Supports NVMe SSD as boot disks
•
1 x Vertical M.2 Socket (Key E) with the bundled WiFi-
802.11ac module (on the rear I/O)

ASROCK B560M-ITX/ac Specifications

General

Processor socket	LGA 1200 (Socket H5)
Processor manufacturer	Intel
Compatible processor series	Intel Celeron, Intel Core i3, Intel Core i5, Intel Core i7, Intel Core i9, Intel Pentium
Maximum number of SMP processors	1
Non-ECC	Yes
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR4-SDRAM
Maximum internal memory	64 GB
Supported memory clock speeds	4400, 4600 MHz
Supported storage drive interfaces	M.2, SATA III
Parallel processing technology support	-
Number of SATA III connectors	4
USB 3.2 Gen 2 (3.1 Gen 2) connectors	0
DisplayPort version	1.4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
LAN controller	Intel® I219-V
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Bluetooth version	4.2
Ethernet interface type	Gigabit Ethernet
Component for	PC
Motherboard chipset	Intel B560
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
BIOS type	UEFI AMI
ACPI version	6.0
System Management BIOS (SMBIOS) version	2.7
Cables included	SATA
Harmonized System (HS) code	84733020

Weight and Dimensions

Width	170 mm
