ASROCK B75M-ITX User Manual

31
2.11 Serial ATA (SATA) / Serial ATA2 (SATA2) / Serial ATA3 (SATA3)
Hard Disks Installation
This motherboard adopts Intel
®
B75 chipset that supports Serial ATA (SATA) / Serial
ATA2 (SATA2) / Serial ATA3 (SATA3) hard disks. You may install SATA / SATA2 /
SATA3 hard disks on this motherboard for internal storage devices. This section will
guide you to install the SATA / SATA2 / SATA3 hard disks.
STEP 1: Install the SATA / SATA2 / SATA3 hard disks into the drive bays of your
chassis.
STEP 2: Connect the SATA power cable to the SATA / SATA2 / SATA3 hard disk.
STEP 3: Connect one end of the SATA data cable to the motherboard’s SATA2 /
SATA3 connector.
STEP 4: Connect the other end of the SATA data cable to the SATA / SATA2 /
SATA3 hard disk.
2.12 Hot Plug Function for SATA / SATA2 / SATA3 HDDs
This motherboard supports Hot Plug function for SATA / SATA2 / SATA3 in AHCI
mode. Intel
®
B75 chipset provides hardware support for Advanced Host controller
Interface (AHCI), a new programming interface for SATA host controllers developed
through a joint industry effort.
NOTE
What is Hot Plug Function?
If the SATA / SATA2 / SATA3 HDDs are NOT set for RAID con guration, it
is called “Hot Plug” for the action to insert and remove the SATA / SATA2 /
SATA3 HDDs while the system is still power-on and in working condition.
However, please note that it cannot perform Hot Plug if the OS has been
installed into the SATA / SATA2 / SATA3 HDD.

ASROCK B75M-ITX Specifications

General

ECC	No
Non-ECC	Yes
Memory voltage	1.5 V
Memory channels	Dual-channel
Memory slots type	DIMM
Number of memory slots	2
Supported memory types	DDR3-SDRAM
Maximum internal memory	16 GB
Supported memory clock speeds	1066, 1333, 1600 MHz
Supported memory module capacities	1GB, 2GB, 4GB, 8GB
System bus rate	5 GT/s
Processor socket	LGA 1155 (Socket H2)
Processor manufacturer	Intel
Compatible processor series	Intel Core i3, Intel Core i5, Intel Core i7
Maximum number of SMP processors	1
Number of SATA II connectors	3
Number of Parallel ATA connectors	0
HDMI version	1.4a
Headphone outputs	5
USB 2.0 ports quantity	4
Audio chip	Realtek ALC892
Cooling type	Passive
Certification	FCC, CE, WHQL, ErP/EuP Ready
Component for	PC
Power source type	ATX
Motherboard chipset	Intel B75
PC health monitoring	CPU, FAN, Temperature
Audio output channels	7.1 channels
Motherboard form factor	mini ITX
Compatible operating systems	Windows 7, Vista, XP 32/64-bit
Supported storage drive interfaces	SATA II, SATA III
Cables included	SATA
Graphics card	HD Graphics
OpenGL version	3.2
DirectX version	11
Maximum resolution	2048 x 1536 pixels
Maximum graphics card memory	1760 MB
Parallel processing technology support	Not supported
PCI Express slots version	3.0
PCI Express configurations	1x16
LAN controller	Realtek RTL8111E
Networking features	Gigabit LAN
Ethernet interface type	Gigabit Ethernet
BIOS type	EFI AMI
ACPI version	1.1
BIOS memory size	64 Mbit

Weight and Dimensions

Width	170 mm
