ASROCK B760 TW/D4 V2 User Manual

English
7
B760 TW/D4 V2
No. Description
1 8 pin 12V Power Connector (ATX12V1)
2 4 pin 12V Power Connector (ATX12V2)
3 2 x 288-pin DDR4 DIMM Slots (DDR4_A1, DDR4_B1)
4 CPU Fan Connector (CPU_FAN1)
5 2 x 288-pin DDR4 DIMM Slots (DDR4_A2, DDR4_B2)
6 CPU/Water Pump Fan Connector (CPU_FAN2/WP)
7 Chassis/Water Pump Fan Connector (CHA_FAN5/WP)
8 Chassis/Water Pump Fan Connector (CHA_FAN3/WP)
9 RGB LED Header (RGB_LED2)
10 Addressable LED Header (ADDR_LED2)
11 ATX Power Connector (ATXPWR1)
12 USB 3.2 Gen1 Header (USB32_6_7)
13 USB 3.2 Gen1 Header (USB32_8_9)
14 SATA3 Connector (SATA3_3)
15 SATA3 Connector (SATA3_2)
16 Post Status Checker (PSC)
17 SPI TPM Header (SPI_TPM_J1)
18 System Panel Header (PANEL1)
19 SATA3 Connector (SATA3_1)
20 SATA3 Connector (SATA3_0)
21 Chassis/Water Pump Fan Connector (CHA_FAN4/WP)
22 Clear CMOS Jumper (CLRMOS1)
23 Chassis/Water Pump Fan Connector (CHA_FAN2/WP)
24 USB 2.0 Header (USB_3_4)
25 USB 2.0 Header (USB_5_6)
26 RGB LED Header (RGB_LED1)
27 Addressable LED Header (ADDR_LED1)
28 Chassis Intrusion and Speaker Header (SPK_CI1)
29 Front Panel Audio Header (HD_AUDIO1)
30 5-pin underbolt AIC Connector (TB1)
31 Chassis/Water Pump Fan Connector (CHA_FAN1/WP)
