ASROCK B760 TW/D4 V2 User Manual

English
31
B760 TW/D4 V2
USB 3.2 Gen1 Headers
Ver tica l:
(19-pin USB32_6_7) (see p.6, No. 12)
Right Angle:
(19-pin USB32_8_9) (see p.6, No. 13)
ere are two headers on this motherboard. Each USB 3.2 Gen1 header can
support two ports.
1
IntA_PB_D+
Dummy
IntA_PB_D-
GND
IntA_PB_SSTX+
GND
IntA_PB_SSTX-
IntA_PB_SSRX+
IntA_PB_SSRX-
VbusVbus
Vbus
IntA_PA_SSRX-
IntA_PA_SSRX+
GND
IntA_PA_SSTX-
IntA_PA_SSTX+
GND
IntA_PA_D-
IntA_PA_D+
USB32_6_7
USB32_8_9
1
IntA_PB_D+
Dummy
IntA_PB_D-
GND
IntA_PB_SSTX+
GND
IntA_PB_SSTX-
IntA_PB_SSRX+
IntA_PB_SSRX-
VbusV
VbusV
IntA_PA_SSRX-
IntA_PA_SSRX+
GND
IntA_PA_SSTX-
IntA_PA_SSTX+
GND
IntA_PA_D-
IntA_PA_D+
