Step 3
Before installing a M.2 SSD
module, please loosen the screws to
remove the M.2 heatsink.
*Please remove the protective lms
on the bottom side of the M.2
heatsink before you install a M.2
SSD module.
B
A
Step 4
Peel o the yellow protective lm on
the nut A. Prepare the M.2 stando
that comes with the package, and
hand tighten it into the nut A. Skip
Step 4 if your M.2 SSD module is
Type 2280.
AB
AB
20
o
Step 5
Align and gently insert the M.2 SSD
module into the M.2 slot. Please
be aware that the M.2 SSD module
only ts in one orientation.
1
1
2
