ASROCK B85M Specifications

2
English
No. Description
1 ATX 12V Power Connector (ATX12V1)
2 CPU Fan Connector (CPU_FAN1)
3 CPU Fan Connector (CPU_FAN2)
4 Power Fan Connector (PWR_FAN1)
5 2 x 240-pin DDR3 DIMM Slots (DDR3_A1, DDR3_A2)
6 ATX Power Connector (ATXPWR1)
7 SATA2 Connector (SATA_5)
8 SATA2 Connector (SATA_4)
9 SATA3 Connector (SATA_0)
10 SATA3 Connector (SATA_1)
11 SATA3 Connector (SATA_3)
12 USB 3.0 Header (USB3_2_3)
13 SATA3 Connector (SATA_2)
14 Clear CMOS Jumper (CLRCMOS1)
15 System Panel Header (PANEL1)
16 Chassis Speaker Header (SPEAKER1)
17 USB 2.0 Header (USB6_7)
18 USB 2.0 Header (USB8_9)
19 Chassis Fan Connector (CHA_FAN1)
20 TPM Header (TPMS1)
21 Print Port Header (LPT1)
22 COM Port Header (COM1)
23 Infrared Module Header (IR1)
24 Chassis Intrusion Header (CI1)
25 Front Panel Audio Header (HD_AUDIO1)
26 SPDIF Out Connector (SPDIF_OUT)
27 Chassis Fan Connector (CHA_FAN2)

ASROCK B85M Specifications

General

Form Factor	Micro ATX
Chipset	Intel B85
Socket	LGA 1150
Maximum Memory	32GB
Memory Slots	4
Memory Standard	DDR3
PCIe Slots	1 x PCIe 3.0 x16
SATA Ports	4 x SATA3 6Gb/s, 2 x SATA2 3Gb/s
USB Ports	8 x USB 2.0
LAN	Realtek RTL8111GR
Video Outputs	1 x DVI-D, 1 x D-Sub
