B85M
3
English
I/O Panel
No. Description No. Description
1 USB 2.0 Ports (USB01) 8 Microphone (Pink)
2 D-Sub Port 9 Optical SPDIF Out Port
3 LAN RJ-45 Port* 10 USB 3.0 Ports (USB3_01)
4 Central / Bass (Orange) 11 USB 2.0 Ports (USB45)
5 Rear Speaker (Black) 12 HDMI Port
6 Line In (Light Blue) 13 DVI-D Port
7 Front Speaker (Lime)** 14 PS/2 Keyboard Port
8914 10111213
1 2 3 5
4
7
6

Other manuals for ASROCK B85M

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the ASROCK B85M and is the answer not in the manual?

ASROCK B85M Specifications

General IconGeneral
Form FactorMicro ATX
ChipsetIntel B85
SocketLGA 1150
Maximum Memory32GB
Memory Slots4
Memory StandardDDR3
PCIe Slots1 x PCIe 3.0 x16
SATA Ports4 x SATA3 6Gb/s, 2 x SATA2 3Gb/s
USB Ports8 x USB 2.0
LANRealtek RTL8111GR
Video Outputs1 x DVI-D, 1 x D-Sub
