ASROCK B85M User Manual

B85M
3
English
•
Supports HDMI Technology with max. resolution up to
1920x1200 @ 60Hz
•
Supports DVI-D with max. resolution up to 1920x1200 @
60Hz
•
Supports D-Sub with max. resolution up to 1920x1200 @
60Hz
•
Supports Auto Lip Sync, Deep Color (12bpc), xvYCC and
HBR (High Bit Rate Audio) with HDMI (Compliant HDMI
monitor is required)
•
Supports HDCP function with DVI-D and HDMI ports
•
Supports Full HD 1080p Blu-ray (BD) playback with DVI-D
and HDMI ports
Audio
•
7.1 CH HD Audio with Content Protection (Realtek ALC892
Audio Codec)
•
Premium Blu-ray audio support
LAN
•
PCIE x1 Gigabit LAN 10/100/1000 Mb/s
•
Qualcomm® Atheros® AR8171
•
Supports Qualcomm® Atheros® Security Wake On Internet
Technology
•
Supports Wake-On-LAN
•
Supports Energy Ecient Ethernet 802.3az
•
Supports PXE
Rear Panel
I/O
•
1 x PS/2 Keyboard Port
•
1 x D-Sub Port
•
1 x DVI-D Port
•
1 x HDMI Port
•
1 x Optical SPDIF Out Port
•
4 x USB 2.0 Ports
•
2 x USB 3.0 Ports
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jack: Rear Speaker / Central / Bass / Line in / Front
Speaker / Microphone

ASROCK B85M Specifications

General

Form Factor	Micro ATX
Chipset	Intel B85
Socket	LGA 1150
Maximum Memory	32GB
Memory Slots	4
Memory Standard	DDR3
PCIe Slots	1 x PCIe 3.0 x16
SATA Ports	4 x SATA3 6Gb/s, 2 x SATA2 3Gb/s
USB Ports	8 x USB 2.0
LAN	Realtek RTL8111GR
Video Outputs	1 x DVI-D, 1 x D-Sub
