ASROCK B85M User Manual

2
English
1.2 Specications
Platform
•
Micro ATX Form Factor
•
All Solid Capacitor design
CPU
•
Supports 4
th
Generation Intel® Core
TM
i7 / i5 / i3 / Xeon® /
Pentium® / Celeron® in LGA1150 Package
•
4 Power Phase Design
•
Supports Intel® Turbo Boost 2.0 Technology
Chipset
•
Intel® B85
•
Supports Intel® Small Business Advantage 2.0
Memory
•
Dual Channel DDR3 Memory Technology
•
2 x DDR3 DIMM slots
•
Supports DDR3 1600/1333/1066 non-ECC, un-buered
memory
•
Max. capacity of system memory: 16GB
(see CAUTION)
•
Supports Intel® Extreme Memory Prole (XMP)1.3/1.2
Expansion
Slot
•
1 x PCI Express 3.0 x16 slot (PCIE1: x16 mode)
•
1 x PCI Express 2.0 x16 slot (PCIE2: x4 mode)
•
2 x PCI slots
•
Supports AMD Quad CrossFireX
TM
and CrossFireX
TM
Graphics
•
Intel® HD Graphics Built-in Visuals and the VGA outputs can
be supported only with processors which are GPU integrated.
•
Supports Intel® HD Graphics Built-in Visuals : Intel® Quick
Sync Video with AVC, MVC (S3D) and MPEG-2 Full
HW Encode1, Intel® InTru
TM
3D, Intel® Clear Video HD
Technology, Intel® Insider
TM
, Intel® HD Graphics 4600
•
Pixel Shader 5.0, DirectX 11.1
•
Max. shared memory 1792MB
•
ree VGA Output options: D-Sub, DVI-D and HDMI
•
Supports Triple Monitors

ASROCK B85M Specifications

General

Form Factor	Micro ATX
Chipset	Intel B85
Socket	LGA 1150
Maximum Memory	32GB
Memory Slots	4
Memory Standard	DDR3
PCIe Slots	1 x PCIe 3.0 x16
SATA Ports	4 x SATA3 6Gb/s, 2 x SATA2 3Gb/s
USB Ports	8 x USB 2.0
LAN	Realtek RTL8111GR
Video Outputs	1 x DVI-D, 1 x D-Sub
