Rear Panel
I/O
•
2 x Antenna Ports
•
1 x PS/2 Mouse/Keyboard Port
•
2 x HDMI Ports
•
1 x Optical SPDIF Out Port
•
2 x USB 2.0 Ports (Supports ESD Protection)
* 1 x Fatal1ty Mouse Port (USB 2.0) is included
•
1 x USB 3.0 Type-A Port (Supports ESD Protection)
•
1 x USB 3.0 Type-C Port (Supports ESD Protection)
•
2 x USB 3.0 Ports (Supports ESD Protection)
•
1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED
LED)
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone (Gold Audio Jacks)
Storage
•
4 x SATA3 6.0 Gb/s Connectors, support RAID (RAID 0,
RAID 1 and RAID 10), NCQ, AHCI and Hot Plug
•
1 x Ultra M.2 Socket, supports M Key type 2280 M.2 SATA3
6.0 Gb/s module and M.2 PCI Express module up to Gen3 x4
(32 Gb/s) (with Ryzen Series CPU) or Gen3 x2 (16 Gb/s) (with
A-Series APU)*
* Supports NVMe SSD as boot disks
* Supports ASRock U.2 Kit
Connector
•
1 x LPC Header
•
1 x AMD Fan LED Header
•
1 x CPU Fan Connector (4-pin)
* e CPU Fan Connector supports the CPU fan of maximum
1A (12W) fan power.
•
1 x Chassis Fan Connector (4-pin)
•
1 x Chassis Optional/Water Pump Fan Connector (4-pin)
(Smart Fan Speed Control)
* e Chassis Optional/Water Pump Fan supports the water
cooler fan of maximum 1.5A (18W) fan power.
* CHA_FAN1/W_PUMP can auto detect if 3-pin or 4-pin fan is
in use.
•
1 x 24 pin ATX Power Connector
•
1 x 8 pin 12V Power Connector (Hi-Density Power
Connector)
•
1 x Front Panel Audio Connector
•
1 x AMD LED Fan USB Header
