English
Fatal1ty Z97 Professional Series
Rear Panel
I/O
•
1 x PS/2 Mouse/Keyboard Port
•
1 x HDMI Port
•
1 x DisplayPort 1.2
•
1 x Optical SPDIF Out Port
•
1 x eSATA Connector
•
3 x USB 2.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
•
1 x Fatal1ty Mouse Port (USB 2.0) (Supports ESD Protection
(ASRock Full Spike Protection))
•
4 x USB 3.0 Ports (Supports ESD Protection (ASRock Full
Spike Protection))
•
2 x RJ-45 LAN Ports with LED (ACT/LINK LED and SPEED
LED)
•
1 x Clear CMOS Switch
•
HD Audio Jacks: Rear Speaker / Central / Bass / Line in /
Front Speaker / Microphone
Storage
•
6 x SATA3 6.0 Gb/s Connectors by Intel® Z97, support RAID
(RAID 0, RAID 1, RAID 5, RAID 10, Intel Rapid Storage
Technology 13 and Intel Smart Response Technology), NCQ,
AHCI, Hot Plug and ASRock HDD Saver Technology
•
2 x SATA3 6.0 Gb/s Connectors by ASMedia ASM1061,
support NCQ, AHCI, Hot Plug and ASRock HDD Saver
Technology (SATA3_A2 connector is shared with the eSATA
port)
•
2 x SATA Express Connectors (SATAE_0 is shared with
SATA3_1 and SATA3_2; SATAE_1 is shared with SATA3_4,
SATA3_5 and M.2 Socket)
* Support to be announced
•
1 x eSATA Connector by ASMedia ASM1061, supports NCQ,
AHCI and Hot Plug
•
1 x M.2_SSD (NGFF) Socket 3, supports M.2 SATA3 6.0 Gb/
s module and M.2 PCI Express module up to Gen2 x2 (10
Gb/s)
Connector
•
1 x COM Port Header
•
1 x TPM Header
•
1 x Power LED Header
•
2 x CPU Fan Connectors (1 x 4-pin, 1 x 3-pin)
